Matrix 3200/6400 Series Part Numbers

A-1
Part Numbers for Matrix 3200/6400 switchers use the following format:
60-25x-iofr
where:
An example of a typical Matrix 3200/6400 part number follows:
60-250-HD11
For this example: x = 0 = Matrix 6400 Wideband
io = HD = 64x32 which was obtained from the Matrix 6400
Wideband Part Number Table on Page A-2.
f = 1 = yes = Front Panel Controller
r = 1 = yes = Redundant Power Supply
For the example above, the io characters would be HD for matrix size 64x32, DD
for matrix size 32x32 and PH for matrix size 64x64.
The Matrix 3200 Wideband and Matrix 6400 Audio io characters are selected
using the same procedure as is used with the Matrix 6400 Wideband, but with
different tables as shown on Pages A-2 and A-3.
The io characters for the Matrix 3200 Sync part number are DD as it is only
available in one matrix size, 32x32. The io characters for the Matrix 6400 Sync
part numbers are PH as it is also available in only one matrix size, 64x64. Either
of the two Sync part numbers may include r = 0 or 1 but f must be 0 as a Sync
module cannot have a Front Panel Controller.
Matrix 3200/6400 Part Numbers (with matrix tables) are shown on Pages A-2
and A-3.
Appendix A • Reference Information
x = 0 = Matrix 6400 Wideband
x = 1 = Matrix 3200 Wideband
x = 2 = Matrix 6400 Video
x = 3 = Matrix 3200 Video
x = 4 = Matrix 6400 Sync
x = 5 = Matrix 3200 Sync
x = 6 = Matrix 6400 Audio
io = Inputs/Outputs (Matrix size). The i and the o
are replaced by two characters which identify the
exact size of the Matrix.
f = Front Panel Controller (FPC-1000)
f = 0 = No, f = 1 = Yes
r = Redundant Power Supply
r = 0 = No, r = 1 = Yes
Extron • Matrix 3200/6400 Series • User's Manual
