Binary/Hex/Decimal Conversion Table

A-5
Pre-cut Cables
The BNC-4 HR is used for RGBS cable runs and the BNC-5 is used for RGBHV
cable runs, but either type can also be used for composite video, S-Video or
RGB with sync on green. All Extron BNC cables have male gender connectors
on both ends. Also available is a plenum version of the BNC-5 HR cabling.
BNC-4 HR Cable
BNC-4-25'HR (25 feet/7.5 meters)
BNC-4-50'HR (50 feet/15.0 meters)
BNC-4-75'HR (75 feet/23.0 meters)
BNC-4-100'HR (100 feet/30.0 meters)
BNC-4-150'HR (150 feet/45.0 meters)
BNC-4-200'HR (200 feet/60.0 meters)
BNC-4-250'HR (250 feet/75.0 meters)
BNC-4-300'HR (300 feet/90.0 meters)
BNC-5 HR Cable
BNC-5-25'HR (25 feet/7.5 meters)
BNC-5-50'HR (50 feet/15.0 meters)
BNC-5-75'HR (75 feet/23.0 meters)
BNC-5-100'HR (100 feet/30.0 meters)
BNC-5-150'HR (150 feet/45.0 meters)
BNC-5-200'HR (200 feet/60.0 meters)
BNC-5-250'HR (250 feet/75.0 meters)
BNC-5-300'HR (300 feet/90.0 meters)
____ Bulk cable in lengths up to 5000' rolls is available with or without connectors.
Decimal value n/a
Dec. Hex Add the decimal values above for equivalents.
0 80/00h n/a
1 81/01h n/a
2 82/02h n/a
3 83/03h n/a
4 84/04h n/a
5 85/05h n/a
6 86/06h n/a
7 87/07h n/a
8 88/08h n/a
9 89/09h n/a
10 8A/0Ah n/a
11 8B/0Bh n/a
12 8C/0Ch n/a
13 8D/0Dh n/a
14 8E/0Eh n/a
15 8F/0Fh n/a
16 90/10h n/a
etc.
32 A0/20h n/a
etc.
64 C0/40h n/a
etc.
99 E3/63h n/a
100 E4/64h n/a
etc.
127 FF/7F n/a
Appendix A • Reference Information
64 32 16
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 1
0 1 0
1 0 0
1 1 0
1 1 0
1 1 1
