Specifications

Power LED — Indicates power is applied.
4
Loop connector — Provides passive loop-through for signal
5
High Z / 75 Ohm switch — Select 75-ohm termination on
6
or off.
High Z — Select this position (up) if you are
connecting a terminated device to the Loop connector.
75 Ohm — This position (down) terminates the Input
connector with 75 ohms of impedance. Select this
position if you are not using the Loop connector, or if
you are connecting an unterminated device to the
Loop connector.
Audio input (left and right) connectors — Connect
7
unbalanced stereo to this RCA connector
Audio output (1 through 5, left and right) connectors —
8
Connect up to five audio (stereo) devices to these RCA
connectors.
Specifications
Video
Gain ................................................... Unity
Bandwidth
MDA 5SV ............................. 270 MHz (-3dB)
MDA 5V ............................... 435 MHz (-3dB)
Differential phase error .................. 0.05º, 0 to 50 MHz
Differential gain error .................... <0.05%, 0 to 50 MHz
Video input
Number/signal type
MDA 5SV ............................. 1 NTSC/PAL/SECAM S-video
MDA 5V ............................... 1 NTSC/PAL/SECAM composite video
Connectors
MDA 5SV ............................. 1 4-pin mini DIN female
MDA 5V ............................... 1 BNC female
Nominal levels ................................. Composite video and Y of S-video: 1V p-p
Minimum/maximum level(s)
MDA 5SV ............................. Y: 0.4V to 2.0V p-p with no offset
MDA 5V ............................... 0.4V to 2.0V p-p with no offset
Impedance ........................................ 75 ohms
Return loss ........................................ <-40dB @ 0 to 10 MHz for MDA 5V
Maximum DC offset ....................... 1.0V
6 MDA 5V, 5SV, 5A RCA • Specifications
C of S-video: 0.3V p-p
<-25dB @ 0 to 10 MHz for MDA 5SV
Video output
Number/signal type
MDA 5SV ............................. 6 S-video: 5 buffered for distribution, 1
MDA 5V ............................... 6 composite video: 5 buffered for
Connectors
MDA 5SV ............................. 6 4-pin mini-DIN
MDA 5V ............................... 6 BNC female
Nominal levels ................................. Composite video and Y of S-video: 1V p-p
Minimum/maximum level(s) ....... 0.4V to 2.0V p-p
Impedance ........................................ 75 ohms
Return loss ........................................ -30dB @ 5 MHz
DC offset ........................................... ±5mV maximum with input at 0 offset
Sync
Standards .......................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Audio — MDA 5A RCA
Gain ................................................... Unity (0dB)
Frequency response ........................ 20 Hz to 20 kHz, ±0.05dB
THD + Noise .................................... 0.03% @ 1 kHz at nominal level
S/N .................................................... >90 dB, at rated maximum output drive
Stereo channel separation .............. >80 dB @ 1 kHz; >60 dB @ 20 kHz
CMRR ................................................ >75 dB @ 20 Hz to 20 kHz
Audio input — MDA 5A RCA
Number/signal type ...................... 1 stereo unbalanced
Connectors ....................................... 2 RCA connectors
Impedance ........................................ >10 kohms unbalanced, DC coupled
Nominal levels ................................. Compatible with -10dBV (316mV), +4dBu
Maximum level ............................... +18 dBu unbalanced at 1%THD+N
Audio output — MDA 5A RCA
Number/signal type ...................... 5 stereo, unbalanced
Connectors ....................................... 10 RCA connectors
Impedance ........................................ 50 ohms unbalanced
Gain error ......................................... ±0.1dB channel to channel
Nominal levels ................................. Compatible with -10dBV (316mV), +4dBu
Maximum level (Hi-Z) ................... >+18dBu, unbalanced at 1%THD+N
0dBu = 0.775 volts (RMS).
MDA 5V, 5SV, 5A RCA • Specifications
passive loop-through
distribution, 1 passive loop-through
C of S-video: 0.3V p-p
(1.23V), 0dBu (0.775V), -20dBV (100mV)
(1.23V), 0dBu (0.775V), -20dBV (100mV)
