1
1
S
ETTING UP THE
Important:

Figure 1-5: Connecting the Jukebox With Other SCSI Peripherals

NEXT
PREVIOUS
JUMP
CONTENTS
INDEX
The default IDs for the jukebox are as follows. Check to see if there will be any conflicts in this installation. If you are
installing another of this model jukebox on the same bus you have conflicts.
Autochanger (jukebox robotics) = 3
J
UKEBOX
Although this jukebox connects to a 68-pin SE/LVD "wide" SCSI bus and host adapter, the jukebox and its optical drives use
a 50-pin "narrow" SCSI bus internally. See Appendix B for a discussion of SCSI buses.
Do not force "wide" data transfers
.
14
