Configuring the Printer's AppleTalk Network Settings

Follow the steps below to configure the AppleTalk network settings.
1.
Start the web browser and enter the following URL in the Location (or Address) box to display the RemoteUI
page.
http://printer IP address or name/
Example: http://xxx.xxx.xxx.xxx/
2.
Select Administrator Mode and click Logon.
3.
If a password has been set on the printer, enter the password.
4.
Click Network in the Device Manager menu at left to display the Network page.
5.
Click Edit in the upper-right corner of the AppleTalk group to display the Edit AppleTalk Protocol Settings
page.
6.
Refer to the AppleTalk Settings Items table to complete the settings.
AppleTalk Settings Items
Item
Phase Specify whether to use AppleTalk.
Type If you will use AppleTalk, choose Phase 2.
If you will not use AppleTalk, choose Disabled.
Name Specify the object name used by AppleTalk (in up to 31 single-byte or 15 double-
(*1) byte characters).
However, do not use the following single-byte characters: @, *, :, and =.
Zone (*2) Specify the printer zone name, up to 31 single-byte characters.
However, do not use the following single-byte characters: Also avoid using * (which
represents the default zone) in the middle of a string.
*1: The object name you have specified in Name is displayed in Printer Setup Utility (or Print Center) in Mac OS
X 10.2.8–10.4. If you use multiple printers in the same zone, assign a unique name to each printer. By default,
the network interface name is Canon NB-18GB (xxxxxx). (Here, xxxxxx is the last six digits of the printer's
MAC address.)
*2: If zones have been created on the network, enter the name of the printer's zone. If there are no zones, leave the
asterisk * entry (for the default zone) as it is. If you enter a network zone name that does not match created
zones, the printer will not be detected by Macintosh computers. Consult your network administrator for informa-
tion on zone names.
7.
Click OK to display the Network page.
iPF750
Details
Configuring the Printer's AppleTalk Network Settings
Network Setting > Mac OS X Settings
Default Setting
Disabled
Canon
NB-18GB
(xxxxxx)
*
>
