HP-GL/2 problems

With HP-GL/2, printing is misaligned .............................................................................................................. 799

Lines or images are missing in printed HP-GL/2 jobs. ................................................................................... 799

Lines are printed too thick or thin in HP-GL/2 print jobs ................................................................................. 799

HP-GL/2 jobs are printed in monochrome (or color) ...................................................................................... 800
Printed colors of lines are inaccurate during HP-GL/2 printing ...................................................................... 800
HP-GL/2 jobs are printed 6 mm larger than specified .................................................................................... 800
HP-GL/2 jobs are printed at maximum size, even if a standard size is specified .......................................... 800
HP-GL/2 printing takes a long time ................................................................................................................. 800
Replotting with HP-GL/2 jobs is not possible. ................................................................................................. 801
The printer stops when printing a HP-GL/2 job (the carriage stops moving) ................................................. 801
With HP-GL/2, printing is misaligned
The plotter origin is incorrect.
The Margin setting in the Control Panel menu is incor-
rect.
Lines or images are missing in printed HP-GL/2 jobs.
The memory is full.
An HP-GL/2 command not supported by this printer was re-
ceived.
The printer has received print data that includes HP RTL com-
mands when Auto Rotate is On in the Control Panel menu.
Lines are printed too thick or thin in HP-GL/2 print jobs
Cause
The Width setting in the
Control Panel menu is in-
correct.
iPF750
Cause
Cause
Check the Width setting value specified for Pen no. in Palette A or Palette B in the
Control Panel menu. If fine lines are printed faintly, setting ThickenFineLines to On
will print the lines more distinctly.
(See "Menu Settings.")
Corrective Action
Check the printing commands.
Adjust the Margin setting values in the Control Panel
menu.
Corrective Action
Check the size of the data in the print job.
Check the print job and settings.
In the Control Panel, set Auto Rotate to Off and
print again.
(See "Menu Settings.")
Corrective Action
→P.673
Troubleshooting > HP-GL/2 problems
→P.673
With HP-GL/2, printing is misaligned
>
11
799
