Replacing Cabinets

Follow these instructions to replace the InterRAID-6, InterRAID-8, or InterRAID-12
cabinet.
To replace a cabinet:
1. Remove the new cabinet from the shipping carton and inspect the shipment. Save the
packaging material.
2. Open the door of the old cabinet. Note the position of each disk drive in the old cabinet.
The drives are labeled with an ID number.
3. Place the new cabinet adjacent to the old cabinet.
4. Shutdown and power off the system base unit; then, power off the cabinet to be replaced.
5. Disconnect the AC power cord and RAID SCSI cable(s) from the old disk array.
6. Connect the AC power cord and RAID SCSI cable(s) to the new cabinet.
7. Remove the disk drives from the old cabinet and install them into the new cabinet in
exactly the same order as they were in the old cabinet.
8. Power on the new cabinet.
9. Power on the system base unit.
