The channel indicator light on each channel icon indicates the status of that channel. The
Deactivate option lasts for 60 seconds when invoked.

Defining Power Console Menu Options

The Power Console menu options are as follows:
Option
Adapter
Physical Drv
Logical Drv
Window
Help
The MegaRAID BIOS Configuration utility and the Power Console utility detect the
presence of RAID controllers, and assign controller numbers, in two different ways. In
InterServe 650, 660 systems, the BIOS and Power Console assign controller numbers as
follows:
u
BIOS lists the controllers starting from PCI slot 7 to PCI slot 4, and counts them
incrementally from 0 to 3.
u
Power Console counts the controllers incrementally from 0 to 3, but lists the controllers
starting from the lowest numbered PCI slot to PCI slot 7. The number assigned to the
controller shifts according to the number of installed controllers.
The following table shows how both utilities list up to four installed RAID controllers:
PCI Slot
7
6
5
4
Description
Choose this option for the MegaRAID controller-related functions.
You can configure logical drives, enable the speaker, toggle object
identification, invoke the performance monitor, and display the
toolbar by selecting an item from this menu.
Choose this option to rebuild, format, and display the properties of
the physical drives. You can also run diagnostics and select tools
from this option.
Choose this option to create, delete, initialize, check parity, and
display the properties of logical drives.
Choose this option to view the progress of a disk rebuild, diagnostic,
initialization, parity check, reconstruction or to view the performance
monitor.
Choose this option to display information on Power Console.
BIOS Power Console
0 0 1 2
1 0 1
2 0
3
3
2
1
0
113
