Power Supplies

Samtec part numbers SSW-105-22-F-D-VS-K and TSM-105-01-T-DV-P provide a 5-pin, dual-row,
header/socket combination at J3.
DAC can be applied directly to the device. The DAC7716 requires multiple power supplies to operate.
AVDD, AVSS, DVDD, and IOVDD are required to properly power the DAC.
Pin No.
J3.1
J3.2
J3.3
J3.4
J3.5
J3.6
J3.7
J3.8
J3.9
J3.10
The Digital and Analog ground inputs are short-circuited internally through a ground plane.
The dc logic voltage for the DAC7716 (IOVDD) is selectable between +3.3VD, +1.8VD, or +5VD via the
JP8 jumper. These power-supply voltages are referenced to digital ground.
The DAC7716EVM is designed to work in either unipolar and bipolar mode. Each mode requires different
power-supply connections. Consult the
the two operating modes.
5

Reference Voltage

The DAC7716EVM has the ability to use two different reference sources simultaneously for different
output channels. REFA and REFB control the reference voltages for the DAC. Output channels V
V -1 use REFA as a reference. REFB is used as a reference for output channels V
OUT
The evaluation module has three options for supplying reference voltages to the DAC7716. Switch S3
(REFA) and S2 (REFB) can select the reference voltage from the REF5050 (U5), REF5025 (U4) or use an
external reference. The REF5050 supplies 5.0V to the reference. The REF5025 supplies 2.5V to the
reference. These reference voltages are additionally filtered through an RC filter before connecting to the
DAC7716. The TL751L08 is used to voltage regulate +VA to properly power the REF5025 and REF5050.
When using an external reference, make sure that the ground terminal (from the external source) is
connected to the ground of the EVM board. There is a built-in diode in the DAC7716 that does not allow
the RefGND-A/RefGND-B to have more than a 0.3V difference from the board AGND on the DAC. A
jumper across pins 2 and 3 on JP6 and JP7 connects the RefGND-A and RefGND-B to the ground of the
board.
SBAU159 – October 2009
Submit Documentation Feedback
Table 3 lists the configuration details for J3. The voltage inputs to the
Table 3. J3 Configuration: Power-Supply Input
Pin Name
+VA
–VA
+5VA
–5VA
DGND
AGND
+1.8VD
+3.3VD
VD1
+5VD
DAC7716 data sheet
Copyright © 2009, Texas Instruments Incorporated
Function
+4.75V to +24V analog supply
–18V to –4.75V analog supply
+5V analog supply
–5V analog supply
Digital ground input
Analog ground input
1.8V digital supply
3.3V digital supply
Not used
+5V
for the restrictions on the power supplies for
Power Supplies
Required
Yes
Yes
No
No
Yes
Yes
Optional
Optional
No
Yes
-0 and
OUT
-2 and V -3.
OUT OUT
5
DAC7716EVM
