Summary of Contents for Fujitsu Mini-ITX D2963-S
- Page 1 Mini-ITX D2963-S Mini-ITX D2963-S TechNotes V1.0 First Release Mainboard OEM Sales - 01/2010 More user manuals on ManualsBase.com...
- Page 2 • Special Features à Page 68 • Operating System Support à Page 71 • OEM FTP download link for D2963-S ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D2963-S/ (provides BIOS; Drivers; Documents & Approvals; Specifications; Tools etc.) TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
-
Page 3: Safety Instructions
(except for the rear I/O connectors) until the mainboard is completely powered down. Any damage caused to the mainboard by misuse of the onboard connectors is excluded from the standard warranty. Fujitsu Technology Solutions cannot be held liable for any damage that results from incorrect use of any onboard connectors. - Page 4 Overview • Onboard interfaces & connectors TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
-
Page 5: Onboard Components
Overview Overview Onboard Components Onboard Components Stereo Audio In/Out Dual-LAN / 4 x USB 2.0 COM1 / DVI-I 2 x PS/2 PCB: 8-layer DC-IN (+ 19…24V) TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com... - Page 6 Drive Power Connector 2 x 2 USB Ports 1 x SO-DIMM LVDS-Backlight Frontpanel GPIO Port Processor CPU Fan 24 Bit Dual Channel LVDS PCIe X1 Frontpanel Audio 19…24V DC-In Buzzer COM 2 TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
-
Page 7: Internal Connectors
Internal Connectors • Optional Devices via Feature Connector • Internal USB/Audio Ports • Compact Flash • Second Serial Port • Frontpanel Connector • PCI / PCIe / Mini-PCIe Extension Slot TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com... - Page 8 (3.3V; 5V; 12V; 5Vaux; max. 1A per pin!) 8 bit 3.3V General Purpose Input/Output (GPIO) in order to attach any digital device (sample picture) IrDA Transceiver Feature (sample picture) Connector TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 9 GPIO features (included in SystemMonitoring API) GPI/O Output High Voltage min. 2.4V Available via OEM FTP Server: Input Leakage Current max. +/- 10µA ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM- Note: max. load per GPI/O pin: 8mA Sales/Products/Mainboards/Industrial&ExtendedLifetime/D2963- S/IndustrialTools_D2963-S/BMC_Management-Controller-API/ TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 10 Internal USB/Audio Ports Internal USB/Audio Ports Connect internal ports to USB/ Audio frontpanel module (Note: 2 USB ports per connector) USB Ports Frontpanel RED = USB Audio BLUE = Audio TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 11 Internal Connectors Internal Connectors Internal USB Ports – Miscellaneous Options Internal USB Ports – Miscellaneous Options Optional: Touchscreen Controller via USB USB Ports TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 12 Internal USB Ports – Miscellaneous Options Internal USB Ports – Miscellaneous Options Optional: Touchscreen Controller via USB Optional: Attach USB Flash Disk Module USB Ports (up to 8GB available) e.g. www.stec-inc.com TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
-
Page 13: Compact Flash
Internal Connectors Internal Connectors Compact Flash Compact Flash CF Card – inserted in socket on mainboard (IDE „Master“-Interface) TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com... -
Page 14: Second Serial Port
Internal Connectors Internal Connectors Second Serial Port Second Serial Port Note: Pinning according FTS standard! External I/O Bracket COM2 Connector TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com... -
Page 15: Front Panel Connector
Internal Connectors Internal Connectors Frontpanel Connector Frontpanel Connector Frontpanel providing - Powerswitch - Power/HDD-LED - Reset-Switch Frontpanel Connector TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com... - Page 16 HDD LED: 5.0V supply max. 10mA onboard 330R series resistor Frontpanel Connector (KEY) Reserved (NC) PowerSwitch_GND ResetSwitch_P PowerSwitch_P ResetSwitch_GND Power_LED_GND HDD_LED- Note: Pinning is compatible to Power_LED+ HDD_LED+ Intel 10 pin header TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 17 - Compliant to 3.3V / 5V devices - Supports up to two PCI master slots via risercards PCI Risercards offered by FTS Note: Third party risercards must not use any “Reserved”-pins of PCI connector! TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 18 PCI Express Extension Slot - PCIe x1 - Provides the option to install customer-specific extension cards - Note: External connectors of PCIe x1 cards require appropriate aperture in chassis rear! TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
- Page 19 Mini PCI Express Extension Slot (bottom side) Mini PCI Express Connector (incl. USB support) Mechanical Lock for Mini PCI Express Card Note: Mini card lock supports full length cards only! TechNotes_D2963_V1.0 Copyright 2010 FUJITSU LIMITED More user manuals on ManualsBase.com...
