user manual
Condenser Dryer
TK K2 E

Advertisement

loading

  Related Manuals for Electrolux TK K2 E

  Summary of Contents for Electrolux TK K2 E

  • Page 1 user manual Condenser Dryer TK K2 E...
  • Page 2 We were thinking of you when we made this product...
  • Page 3 You’ve chosen a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. Electrolux ambition is to offer a wide variety of quality products that would make your life even more comfortable. You can look at some examples on the cover in this manual.
  • Page 4: Table Of Contents

    4 electrolux Contents Operating Instructions Important safety information Product description Control panel Before first use Sorting and preparing laundry Programme overview Daily use Care and cleaning What to do if ... Machine settings Technical data Consumption values Hints for test institutes...
  • Page 5: Operating Instructions

    5 Operating Instructions Important safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is im- portant to ensure that all people using the appliance are thoroughly familiar with its operation and safety features.
  • Page 6 6 electrolux important safety information • Items that have been soiled with substances such as cooking oil acetone, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
  • Page 7 7 • If the tumble dryer is placed on top of a washing machine, it is compulsory to use the stacking kit (optional accessory). • This appliance is designed for domestic use. It must not be used for purposes other than those for which it was designed.
  • Page 8: Product Description

    8 electrolux product description Product description Control panel Drawer with condensed water container Fine strainer (lint filter) Large mesh filter (lint filter) Micro-fine filter (lint filter) Rating plate Loading door (reversible) Base door upstream of heat exchanger Button for opening door in plinth...
  • Page 9: Control Panel

    9 Control panel Programme knob and OFF Aus switch Function buttons Start/Pause button DELAY START Zeitvorwahl button Function and warning leds Before first use In order to remove any residues which may have been produced during production, wipe the dryer drum with a damp cloth or carry out a brief drying cycle (30 MIN) with damp cloths in the machine.
  • Page 10 10 electrolux sorting and preparing laundry • Sorting by care label. The care labels mean: Dry at reduced Drying in the tum- Drying in the tum- Dry at normal temperature ble dryer possible ble dryer not pos- (press DELICATE temperature...
  • Page 11: Programme Overview

    11 Programme overview Additiona l func- tions pplication/properties EXTRA Thorough drying of thick or multi- layered Extratroc • • • fabrics, e.g. terry towelling items, bath- robes. CUP- Thorough drying of fabrics of even BOARD • •...
  • Page 12 12 electrolux programme overview Additiona l func- tions pplication/properties For further drying of individual items of 30 Min. • • • laundry or for small volumes of less than 1kg. FRESHE For refreshing or gently cleaning textiles N UP •...
  • Page 13: Daily Use

    13 Daily use Switching machine on Turn the programme selector to any programme. The machine has been switched on. Led of Start/Pause button is flashing. Opening loading door / loading laundry Open loading door: Use force to push against the loading door (push point) 2.
  • Page 14: Buzzer Function

    14 electrolux daily use DELICATE (Schon) function For especially gentle drying of sensitive fabrics with the care label and for temperature-sensitive textiles (e.g. acrylic, viscose). Programme is executed with reduced heat. DELICATE Schon function is only suitable for use with loads of up to 3kg.
  • Page 15 15 To deselect function press again BUZZER Signal button. Led above is off. DELAY START (Zeitvorwahl) function With the DELAY START Zeitvorwahl button, you can delay the start of a programme by 3, 6 or 9 hours.
  • Page 16: Starting The Programme

    16 electrolux daily use Starting the programme Press the Start/Pause button. Led above stops flashing, becomes steady. The pro- gramme is started. Lighting status LED shows you cycle run. Changing programme To change a programme which has been selected by mistake once the programme has started, first turn the programme selector to OFF Aus position.
  • Page 17 17 Drying cycle complete / removing laundry Once the drying cycle is complete, END status led is lighting. If the BUZZER Sig- nal button has been pressed, an acoustic signal sounds intermittently for about one minute. The drying cycles are automatically followed by an anti-crease phase which lasts around 30 minutes.
  • Page 18: Care And Cleaning

    18 electrolux care and cleaning Care and cleaning Cleaning fluff filter The filters collect all the fluff which accumulates during drying. To ensure that the dryer works perfectly, the fluff filters (micro-fine filter and fine strainer) must be cleaned after every drying cycle.
  • Page 19 19 Remove the filter from the door pulling it out. It can be positioned with the tooth facing to the left or to the right). After cleaning do not forget to put it back. Push down unlock button on large mesh filter.
  • Page 20: Cleaning The Door Seal

    20 electrolux care and cleaning Remove fluff from the entire filter area. It is best to use a vacuum cleaner for this purpose. 9. Press both journals of the large mesh filter into the brackets on the loading door until they snap into place.
  • Page 21 21 If the condensate tank is full, an active programme will break off automatically and the warning led light up. In order to continue the programme, the condensate tank must first be emptied. The condensate is not suitable for drinking or for preparing foodstuffs.
  • Page 22: Cleaning Heat Exchanger

    22 electrolux care and cleaning The condensate can be used as distilled water, e.g. for steam ironing. However first filter the condensate (e.g. with a coffee filter) to remove any residue and small pieces of fluff. Cleaning heat exchanger If the warning led is lighting, the heat exchanger needs to be cleaned.
  • Page 23: Cleaning The Drum

    23 Use the handle to pull the heat exchanger out of the base and carry it horizontally to prevent any remaining water from spilling. 6. To empty the heat exchanger, hold vertically over a washing-up bowl.
  • Page 24 24 electrolux care and cleaning Lime in the water or cleaning agents may form a barely visible lining on the inside of the drum. The degree to which the laundry has been dried is then no longer detected reliably. The laundry is damper than expected when re- moved from the dryer.
  • Page 25: What To Do If

    ... electrolux 25 What to do if ... Troubleshooting by yourself If, during operation, the dryer shows an error (one or more leds flashing on the control panel), check first of all whether you can remedy the problem yourself by means of the table below.
  • Page 26 26 electrolux what to do if ... Fine strainer not in place Install fine strainer and/or Loading door does and/or mesh filter not locked snap large mesh filter into not close. in place. place. When a button is Washing protection. After...
  • Page 27: Machine Settings

    27 Machine settings Setting Implementation BUZZER Signal perma- 1. Turn the programme selector to any pro- nent on/off gramme. 2. Press simultaneously the DELICATE Schon and BUZZER Signal buttons and hold down for ap- prox. 5 seconds the result can be following: –...
  • Page 28 28 electrolux machine settings Water hardness 1. Turn the programme selector to any pro- gramme. 2. Press simultaneously the DELICATE Schon and Start/Pause buttons and hold down for approx. Water contains, a varia- 5 seconds. The current setting is shown by...
  • Page 29 29 Emptying water tank - 1. Turn the programme selector to any pro- warning message perma- gramme. nent off 2. Press simultaneously the BUZZER Signal and DELAY START Zeitvorwahl buttons and hold down for approx. 5 seconds.
  • Page 30: Technical Data

    30 electrolux technical data Technical data This appliance conforms with the following EU Directives: – 73/23/EEC dated 19.02.1973 Low Voltage Directive – 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Di- rective 92/31/EEC – 93/68/EEC dated 22.07.1993 CE Marking Directive...
  • Page 31: Consumption Values

    31 Consumption values The consumption values have been established under standard conditions. They may deviate when the machine is operated in domestic circumstances. Energy consumption Programme Loading volume in kg in kWh COTTON CUPBOARD Baumwolle Schranktrocken COTTON IRON DRY Baum- wolle Bügeltrocken...
  • Page 32: Installation

    32 electrolux installation Installation Appliance positioning • It is recommended that, for your convenience, the machine is positioned close to your washing machine. • The tumble dryer must be installed in a clean place, where dirt does not build up.
  • Page 33: Electrical Connection

    33 Removing transport safety packaging Before use all parts of the transport packaging must be removed. 1. Open loading door 2. Pull off adhesive strips from inside machine on top of drum. Remove foil hose and polystyrene padding from the machine.
  • Page 34: Changing Door Stop

    34 electrolux installation The power supply cable must be accessible after installing the machine. Connect the machine to an earthed socket, in accordance with current wiring regu- lations. Changing door stop The door stop may only be changed by a specialist. If necessary, please contact our after-sales service or your specialist dealer.
  • Page 35 35 4. Use an appropriate tool and exert pressure to unfasten locking block D from the snap-on fixture, take out and re-insert on the other side having rotated the block through 180°. 5. Unscrew hinge A from the loading door, rotate through 180°, re-insert on the opposite side and screw down.
  • Page 36: Environment

    Available from your Service Force Centre or your specialist dealer These intermediate installation kits can be used to arrange the dryer and an automatic AEG-Electrolux washing machine (60cm wide, front loading) as a space- saving washer/dryer stack. The automatic washing machine is at the bottom and the dryer is at the top.
  • Page 37: Old Appliance

    37 Old appliance The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring...
  • Page 38: Environmental Tips

    38 electrolux environment Environmental tips • In the dryer, laundry becomes fluffy and soft. Fabric softeners are not therefore needed when washing. • Your dryer will function most economically if you: – always keep the ventilation slots on the base of the dryer unobstructed;...
  • Page 39: Service

    39 Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instructions (Chapter “What to do if…”). If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners.
  • Page 40 40 electrolux...
  • Page 41 41...
  • Page 42 42 electrolux...
  • Page 44 136901420-01-15102007...
