Reset Switch

The reset switch, located between P3 and CR1, does the
following (depending on how long you hold the switch down):
•
•

LEDs

Digi One EM LEDs provide information on port activity,
diagnostics, and Ethernet activity.
LED
Top left
Top
right
Digi One EM Hardware Reference
It reboots the Digi One EM if you press and release the
switch immediately.
It reboots the Digi One EM and restores the configuration
to factory defaults. (Press and hold the switch down for
about 20 seconds while powering the Digi One EM up.)
Color
Green
Green
Function
•
Indicates serial
port activity
•
•
Network link sta-
tus
•
Interpretation
Off means that the serial
channel is idle.
Blinking indicates an
active connection.
Off means that no link
has been detected.
On means that a link
has been detected.
