Connecting Your Touchmonitor

The following illustrations guide you step by step in connecting your
touchmonitor.
Before connecting the cables to your touchmonitor and PC, be sure that the computer
and the touchmonitor are turned off.
2-8
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
OSD module
connector
Serial
touchscreen
Power Power switch connector
Connections on underside
Female 15-pin
video
connector
Serial cable
US
power cable
European
power cable
Video cable
AUTO/SEL DOWN UP MENU
OSD module
