Mounting Your Touchmonitor

N : You will need a 6mm allen socket and torque wrench (Hex) to attach the mounting
OTE
brackets.
Your panel mount touchmonitor comes with 6 mounting brackets (and 6
screws). You will need 6 brackets to mount your touchmonitor. Two brackets
attach to the top and bottom and one on each side.
To mount your touchmonitor to a panel, follow the steps below:
1
2
3
4
5
6
Prepare the opening in the panel (307mm x 398.2mm/12.08" x 15.68"). See
page C-36. Mounting panel thickness must not exceed 13mm.
Disassemble the 6 brackets and NEMA frame.
Verify that your touchmonitor will clear the opening as you attempt to front
mount it. The opening will be covered by the bezel flanges.
Mount the touchmonitor from the front side of the opening in the supporting
panel and temporarily secure it.
From the back of the panel opening, slip the NEMA frame over the rear
cover. Attach the 6 brackets into the slots. Use 2 brackets on top and bottom
and 1 on each side.
To secure the touchmonitor, turn the screws clockwise until a firm
contact is made with the NEMA frame. To assure a "flat" mount, screws
should be tightened "cris-cross" and not sequentially, i.e. tighten the
upper left corner screw first then the lower right screw. Torque screws
to 35 in lbs. (4 Nm).
