• Connect the female end of the serial (RS-232) cable to the serial port on the
• Connect the male end of the cable to the serial touchscreen connector on your
• Secure the cable to your touchmonitor and PC by turning the screws on the
2-10
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
STEP 2-Connecting the Serial Touchscreen Cable
back of your PC.
touchmonitor.
connector.
Connections on underside
Serial
touchscreen
connector
Serial
touchscreen
cable
