System Status LED Indicators

The LED indicators display the system's operation status.
Icon Color
Green
Red
Green
Red
Blinking Red
Green
Green
Green
Green
Green

Power Button

Use this button to turn the system on or off.
After proper configuration under SCU, this button can be
used as suspend/resume hot button (refer to Chapter 3:
BIOS Utilities, Power Menu for more information).
User's Manual
1-10
Description
Battery power is used while the system is
turned on.
AC power is used while the system is
turned on.
Battery is fully charged.
Battery is being charged.
Battery power is critically low.
The system has entered the configured
suspend mode.
The embedded numeric keypad feature is
activated
The Caps Lock feature is activated.
The Scroll Lock feature is activated.
The hard disk is being accessed.
