About the optional unit

Others

Connecting a portable audio
About the optional unit
player to the AUX jack
Use a commonly available accessory cable with
an RCA connector or an optional AUX105 to
connect a portable audio player to the AUX
(auxiliary) jack of this system.
There are 2 connection terminals on this main
unit; one for the RCA connector and the other for
the optional LAN cable (AUX 105). The default
setting for AUX is OFF.
Turn on the portable audio player
1
and start its play function.
The AUX mode is activated.
For details, refer to "Switching Audio
Modes" on page 17.
ATTENTION
• While the AUX mode is activated, actions
such as turning off the audio player or
pulling out the connection cord may cause
noise spikes that can damage the system
speakers. Be sure to avoid this possibility
by turning off system power or switching
from the AUX mode to another mode before
shutting off or disconnecting the portable
audio player.
• Audio output levels for the various devices
that can be connected using this method
will differ. Carefully adjust the volume until
the output level of the connected player is
known.
• Before using a portable audio player in a
vehicle, read the player's operation manual
carefully and
operation in the vehicle before proceeding.
• When you connect an optional LAN cable
(AUX 105) to the main unit, other optional
equipment that uses E-LAN cannot be
connected.
102
confirm problem-free

Switching the AUX mode on and off

Press the [ /MENU] button for
1
more than one second.
The Menu selection mode is activated.
Select "FUNC" by pressing the [ ]
2
or [ ] button, and then press the
[ENTER] button.
The function mode is activated.
Select the AUX ON/OFF mode by
3
pressing the [ ] or [ ] button.
The AUX ON/OFF mode is activated.
Select the ON or OFF mode by
4
pressing the [ ] or [ ] button.
Press the button to switch the mode as
follows:
[ ]:
ON
[ ]:
OFF
The selected settings will take effect.
