Manually adjusting the equalizer
mode
Select "Parametric EQ" by
1
pressing the [ ] or [ ] button.
2
Press the [ENTER] button.
This changes to the PEQ setting
mode.
Select the band to be adjusted by
3
pressing the [<] or [>] button.
Each time the button is pressed, the
band changes in the following order.
[>]:
1 → 2 → 3 → 4 → 5 → 6 → 7 → 1 →
[<]:
1 → 7 → 6 → 5 → 4 → 3 → 2 → 1 →
Press the [ENTER] button to select
4
the frequency to be adjusted.
Each time the button is pressed, the
frequency to be adjusted changes.
Adjust the frequency level by
5
pressing the [ ] or [ ] button.
[ ]:
Increases the level.
[ ]:
Decreases the level.
Adjust the Q curve pattern by
6
pressing the [ ] or [ ] button for 1
second or more.
Each time the button is pressed, the Q
curve pattern changes in the following
order.
WIDE ↔ Mid WIDE ↔ NORMAL ↔
Mid NARROW ↔ NARROW ↔
WIDE ↔
Repeat the steps 3 to 6 to change
7
the settings for each channel and
band.
How to operate the Sound Adjustment Mode
Press a button from [1] to [4] for
8
more than two seconds to preset a
setting value.
The preset value is overwritten by the
value set using the above steps.
The time alignment and crossover
adjustments will also be stored at this
time.
ATTENTION
The [5] button does not have the equalizer
correction function, and you cannot assign a
setting value to this button.
Selecting an equalizer mode
from memory
Press a preset button to select the equalizer
mode set in memory on the button. The buttons
that set equalizer modes in the memory are
called preset buttons.
Select a button from [1] to [4] and
press it for less than one second
1
while the PEQ setting mode is
activated.
Any of the following patterns can be
read from memory.
Button
[1] Pattern with enhanced treble range
[2] Pattern with enhanced bass and treble
ranges
[3] Pattern with enhanced bass range
[4] Pattern with enhanced vocal range

Resetting the Equalizer mode

You can reset the currently saved equalizer
adjustment value to the default.
Hold down the [5] button for more
1
than two seconds.
"Are you sure to initialize all preset
EQ?" appears on the display.
Pattern
