NOTE Store the processor in a safe place where it will not be damaged.If you are permanently removing
a second processor, check your OS documentation to determine if you should change any OS settings to
disable multiprocessor support or enable Hyper-Threading support.
Replacing the Processor
1 Disconnect power from the system
heatsink (page 105), and remove the processor
2 Raise the processor socket handle fully (the full swing angle of the lever is approximately 135
degrees).
CAUTION Processor pins are delicate and bend easily. Use extreme care when placing the processor in
the socket.
3 Line up the triangle on the top of the processor with the triangle on the corner of the processor socket
and install the processor into the socket. Ensure that the underside of the processor is level with the
top of the processor socket. Lightly press down on the top of the processor while closing the socket
lever.
4 Check for proper processor seating in the socket by carefully trying to lift the processor out of the
socket with your fingers. A properly seated processor does not lift out of the socket.
(page 68), remove the access panel
(page 108).
REMOVAL AND REPLACEMENT OF COMPONENTS 109
(page 74), remove the CPU
