Addressable Fire Alarm Control Panel

MS-9200UDLS

MS-9200UDLSE

MS-9200UDLSC

Manual

Document 52750

7/26/2010

Rev:

P/N 52750:F

ECN 10-365

Table of Contents

Summary of Contents for Fire-Lite MS-9200UDLS

Page 1 Addressable Fire Alarm Control Panel MS-9200UDLS MS-9200UDLSE MS-9200UDLSC Manual Document 52750 7/26/2010 Rev: P/N 52750:F ECN 10-365...
Page 2: Fire Alarm System Limitations
Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system—typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, audible alarm only when heat on their sensors increases at a predeter- warning devices, and a fire alarm control panel with remote mined rate or reaches a predetermined level.
Page 3: Installation Precautions
Installation Precautions Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected to light- sources of power before servicing.
Page 4 Software Downloads In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we strongly recommend that you download the most current version of software for each product prior to commissioning any system.
Page 5: Table Of Contents
Table of Contents Section 1: Product Description ..................... 13 1.1: Features and Options ...........................13 1.2: Specifications...............................15 1.3: Controls and Indicators..........................17 1.4: Digital Alarm Communicator/Transmitter ....................18 1.5: Components ..............................19 1.5.1: Intelligent Addressable Detectors: Newer Series ................19 1.5.2: Intelligent Addressable Modules: Newer Series ................19 1.5.3: 300 Series Intelligent Addressable Devices ..................20 1.5.4: Addressable Device Accessories .......................20 End-of-Line Resistor Assembly ......................20...
Page 6 Table of Contents 2.4: Relays................................51 2.5: Notification Appliance Circuits ........................51 2.5.1: Style Y (Class B) NAC Wiring ......................52 2.5.2: Style Z (Class A) NAC Wiring with ZNAC-92 Converter ...............52 2.6: Remote Synchronization Output........................53 2.7: UL Power-limited Wiring Requirements .....................54 2.8: Digital Communicator ..........................55 2.8.1: Ferrite Clamp Installation ........................56 2.9: Optional Module Installation ........................56 2.9.1: 4XTMF Transmitter Module Installation ..................56...
Page 7 Table of Contents Zones Disabled .............................95 Zone Type.............................96 Zones Available............................97 Zone Message............................97 3.6.4: Loop Setup............................97 Style..............................97 Loop Protocol ............................98 Device Addressing..........................98 3.6.5: System Setup .............................98 Trouble Reminder..........................99 Banner..............................99 Time-Date............................101 Timers..............................103 NAC (Notification Appliance Circuit) ....................105 Relays ..............................111 Canadian Option..........................112 Waterflow Silenceable........................112 3.6.6: Verify Loop .............................113 3.6.7: History .............................113 View Events............................113...
Page 8 Table of Contents 4.6: Supervisory Operation ..........................163 4.7: Process Monitor Operation ........................163 4.8: Hazard/Tornado Condition Operation......................164 4.9: Medical Alert Condition Operation ......................164 4.10: NAC Operation ............................165 4.11: Programmed Zone Operation........................165 4.12: Disable/Enable Operation ........................165 4.13: Waterflow Circuits Operation ........................165 4.14: Detector Functions ...........................165 4.15: Time Functions: Real-Time Clock......................166 4.16: Synchronized NAC Operation .........................166 4.17: Coded Operation ............................166...
Page 9 Table of Contents 7.3.1: Overview ............................189 7.3.2: How to Calculate System Current Load ..................190 7.4: Calculating the Battery Size ........................192 7.4.1: NFPA Battery Requirements ......................192 7.4.2: Selecting and Locating Batteries .....................192 Appendix A: Software Zones ....................194 A.1: Correlations...............................194 Appendix B: Default Programming ..................200 Appendix C: NFPA Standard-Specific Requirements ............
Page 10 NEC Article 300 Wiring Methods NEC Article 760 Fire Protective Signaling Systems Applicable Local and State Building Codes Requirements of the Local Authority Having Jurisdiction (LAHJ) Fire-Lite Documents: Fire-Lite Device Compatibility Document #15384 SLC Wiring Manual Document #51309 ACS Series Annunciators...
Page 11: System Connections
TRANSFORMER 1 TRANSFORMER 2 MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 12 Peripheral Devices and Their Documents: ANN Audio Control for ACC-25/50(ZS/T) Doc. #51889 ANN-(R)LED ANN-RLY LED Display 10 Form-C Relay Card Doc. #53032 Doc. #53033 ANN-I/O ANN-80(C) LED Driver ANN-S/PG LCD Text Annunciator/Indicator Doc. #151416 Printer Driver Doc. #52749 Doc. #151417 IPDACT Internet Communicator ANN-BUS - TB9...
Page 13: Section 1: Product Description
Section 1: Product Description The Fire-Lite MS-9200UDLS is a combination FACP (Fire Alarm Control Panel) and DACT (Digital Alarm Communicator/Transmitter) all on one circuit board. This compact, cost effective, intelligent addressable control panel has an extensive list of powerful features.The combination of Fire-Lite’s newer series devices and legacy 300 Series devices, along with the MS-9200UDLS...
Page 14 Compatible with Fire-Lite’s newer series devices in LiteSpeed and CLIP mode (refer to SLC Wiring Manual for a list of compatible addressable devices) • Compatible with legacy Fire-Lite 300 Series devices in CLIP mode only (refer to the SLC Wiring Manual for a list of compatible addressable devices) •...
Page 15: Specifications
Specifications Product Description • Legacy ACS/TERM Annunciators (cannot be used if ANN annunciators are used): ACS Series-LED Zone Annunciators  LDM Graphic Annunciator Series  LCD-80F Liquid Crystal Display point annunciator  LCD-80FC Remote Fire Indicator (Canadian applications)  ACM-8RF Relay Module ...
Page 16 Product Description Specifications Nonresettable or Resettable Special Application Power (24 VDC Nominal) - TB1, Terminals 1 (+) & 2 (-) Factory-set as nonresettable, suitable for powering annunciators Jumper selectable (JP4) for conversion to resettable power output Maximum ripple voltage: 20mV Total DC current available is up to 1.0 amp (see Figure 1.1 on page 17) Power-limited circuit Resettable or Nonresettable Special Application Power (24 VDC Nominal) - TB1,...
Page 17: Controls And Indicators
Controls and Indicators Product Description The following figure illustrates the maximum current that is possible for each major panel output circuit and the total current available from the FACP. Special Application Nonresettable or 1.0 amp max Standby per circuit Resettable Power 2.0 amps Special Application 1.0 amp max...
Page 18: Digital Alarm Communicator/Transmitter
Product Description Digital Alarm Communicator/Transmitter • Battery fault (yellow) • Ground fault (yellow) Key Panel Mounted on the main circuit board, the key panel includes a window for the LCD display and LED indicators as listed above. The key panel, which is visible with the cabinet door closed, has 25 keys, including a 16 key alpha-numeric pad similar to a telephone keypad.
Page 19: Components
Components Product Description 1.5 Components Main Circuit Board The main circuit board contains the system’s CPU, power supply, other primary components and wiring interface connectors. The 4XTMF option module plugs in and is mounted to the main cir- cuit board. Cabinet The MS-9200UDLS backbox provides space for two batteries (up to 18 Amp Hour).
Page 20: 3: 300 Series Intelligent Addressable Devices
1.5.3 300 Series Intelligent Addressable Devices Fire-Lite’s 300 Series Intelligent Addressable Devices are fully compatible with the MS- 9200UDLS FACP. The address of 300 Series devices cannot be set above 99. Refer to the SLC Wiring Manual for a list of compatible addressable devices.
Page 21: 2: Dp-9692 Dress Panel
Accessories Product Description A standard USB cable with male-A to male-B connectors, which must be purchased separately, is required for local connection of the PC to the USB port J12 on the FACP main circuit board. Remote programming requires that the PC have a 2400 baud (or faster) modem. Important: Remote modification of FACP programming requires that the panel be enabled for remote download (refer to “Remote Site Upload/Download”...
Page 22: 6: Battery Charger
Product Description Accessories 1.7.6 Battery Charger CHG-75 Battery Charger The CHG-75 is capable of charging up to 75 AH lead-acid batteries with the MS-9200UDLS FACP. The FACP battery charger must be disabled, by removing jumper JP5, when using the CHG-75. The charger and up to 26 AH batteries can be housed in the BB-26 battery box. Larger batteries and the charger can be housed in the BB-55F battery box which can be mounted up to 20 feet away from the control panel.
Page 23: Ann-Bus Wiring
Accessories Product Description • The panel is capable of operating a primary ANN-BUS (TB9) and a secondary ANN-BUS (TB8) simultaneously. • The panel is capable of operating the ACS-BUS (connector TB9) and the secondary ANN-BUS (connector TB8) simultaneously. • The secondary ANN-BUS (on connector TB8) does not support legacy ACS annunciators. •...
Page 24: Wiring Distance Calculation Example
Product Description Accessories The following formulas were used to generate the wire distance chart: 6.0 Volts Maximum Resistance (Ohms) Total Worst Case Current Draw (amps) Maximum Resistance (Ohms) Maximum Wire Length (feet) *500 (6,000 feet maximum) where: Rpu = Ohms per 1,000 feet for various Wire Gauges (see table below) Wire Gauge Ohms per 1,000 feet (Rpu) 16.2...
Page 25: Wiring Configuration
Accessories Product Description Wiring Configuration  Figure 1.3 illustrates the wiring between the FACP’s Primary ANN-BUS and ANN-BUS devices. ANN-BUS and power wiring are supervised and power-limited B A (+) (-) 24 VDC nonresettable ANN-BUS Device Primary ANN-BUS TB10 SHIELD B+ A+ B- A- + 24V - + 24V -...
Page 26: Ann-Bus Device Addressing
Product Description Accessories Powering ANN-BUS Devices from an Auxiliary Power Supply  Figure 1.5 illustrates the powering of ANN-BUS devices from an auxiliary power supply such as the FCPS-24FS6/8, when the total ANN-BUS power requirements exceed the panel’s DC Power Output capability.
Page 27: Remote Fire Annunciator
Accessories Product Description Address Switch 5 Switch 4 Switch 3 Switch 2 Switch 1 not valid Switch 5 must be set to OFF for ANN-BUS devices to be recognized. ANN-80 Remote Fire Annunciator The ANN-80 Annunciator is a compact, 80 character, backlit LCD remote fire annunciator. It mimics the display on the control panel and will annunciate device type, point alarm, trouble or supervisory condition, zone assignment plus any custom alpha labels programmed into the FACP.
Page 28 Product Description Accessories Opening/Closing Annunciator  The following procedure details the steps used to open the annunciator in order to access the termi- nal block and DIP switches (refer to figure below): Turn the key switch to the ON (Unlocked) position by turning the key counter-clockwise Push in the snap latch located on the right side of the unit while pulling the cover open To close the cover, make certain the key switch is in the ON (Unlocked) position.
Page 29 Accessories Product Description Wiring ANN-80 to FACP  The following steps can be used as a guide to wire the annunciator. Make certain all power has been removed from the FACP prior to annunciator installation. Route wires from hole in backplate, through wiring channel and then to ANN-80 terminal block TB1 wiring channel wires...
Page 30: Ann-S/Pg Serial/Parallel Interface Installation
Product Description Accessories The following table shows the ANN-80 connections to the MS-9200UDLS. MS-9200UDLS ANN-80 (TB1) Terminal GND (-) on TB1 Terminal 1 (-) Terminal PWR (+)TB1 Terminal 2 (+) Terminal Data (A) on TB9 Terminal 3 (A) Terminal Data (B) on TB9 Terminal 4 (B) Programming Following installation and wiring of the ANN-80 LCD annunciator to the FACP, the annunciator...
Page 31 Accessories Product Description Select the address and configuration options for the ANN-S/PG module as described in the Programming section of this manual (refer to “ANN-BUS Options” on page 120) Note that the Auto-configure feature allows the programmer to quickly bring all installed ANN-BUS modules online (refer to “Auto-Configure”...
Page 32 Product Description Accessories Setting Printer Options Refer to the documentation supplied with the PRN-6F printer for instructions on using the printer menu controls. Set the printer options (under the menu area) as shown in the following table: Option Setting Option Setting Font HS Draft...
Page 33: Ann-I/O Led Driver Module
Accessories Product Description ANN-I/O LED Driver Module The ANN-I/O is an LED driver module that can be used in a wide variety of applications, including as an interface with most customized graphic annunciators. The ANN-I/O can drive up to 40 LEDs.
Page 34 Product Description Accessories ANN-I/O Connection to FACP  The ANN-I/O connects to the FACP via the ANN-BUS as illustrated in Figure 1.9. After the ANN- I/O is connected to the panel, it must be added to the system via FACP programming. Refer to the section titled “ANN-I/O Options”...
Page 35: Ann-Led Annunciator Module
Accessories Product Description Figure 1.10 ANN-I/O LED Wiring ANN-LED Annunciator Module The ANN-LED and ANN-RLED annunciator modules provide LED annunciation of general sys- tem faults and input zones/points when used with a compatible FACP. The ANN-LED module pro- vides alarm (red), trouble (yellow) and supervisory (yellow) indication for up to ten input zones or addressable points.
Page 36 Product Description Accessories Specifications  • Max. ANN-BUS Voltage: 24 VDC • Max. Current: Alarm: 68 mA  Standby: 28 mA  • Operating Temperature: 32 F to 120 F (0 C to 49 • For indoor use in a dry location only Mounting/Installation ...
Page 37: Ann-Rly Annunciator Module
Accessories Product Description ANN-LED Board Layout and Connection to FACP  Figure 1.13 illustrates the ANN-LED board showing locations of screw terminals for connection to the FACP and the DIP switches for selecting the ANN-BUS ID number. ANN-BUS (ID#) Address DIP switch 1 2 3 4 5 6 7 8 ANN-BUS ANN-LED...
Page 38 Product Description Accessories Mounting/Installation  The ANN-RLY relay module can be mounted inside the FACP main circuit board chassis or inside the ROME Series enclosure. Refer to the ANN-RLY Installation Document #53033 for instructions on chassis mounting or to the ROME Series Installation Document #53530 for mounting in the sep- arate backbox.
Page 39: Ann-Bus Audio Panel Control
Accessories Product Description ANN-RLY Board Layout and Connection to FACP  Figure 1.15 illustrates the ANN-RLY board showing locations of screw terminals for connection to the FACP and the DIP switches for selecting the ANN-BUS ID number. ANN-BUS (ID#) Address DIP switch 1 2 3 4 5 6 7 8 ANN-BUS ANN-BUS and power wiring are...
Page 40 Product Description Accessories • FACP Input programmed to Zone 33 goes into alarm, the programmed message for Zone 33 [Message 1, 2, 3, 4 or 5] will play over the ACC-25/50ZS Series output circuit 1 which corresponds to FACP Zone 33. •...
Page 41: 9: Legacy Acs Series Led Zone Type Annunciators
Getting Started Product Description 1.7.9 Legacy ACS Series LED Zone Type Annunciators WARNING: RISK OF ELECTRICAL SHOCK AND EQUIPMENT DAMAGE DISCONNECT ALL SOURCES OF POWER (AC AND DC) BEFORE INSTALLING OR REMOVING ANY MODULES OR WIRING. The legacy ACS annunciators may not be used if new ANN-BUS annunciators are being used on the primary ANN-BUS connector (TB9) due to incompatible serial communication protocols.
Page 42: Telephone Requirements And Warnings
Before connecting the control panel to the public switched telephone network, the installation of two RJ31X jacks is necessary. If trouble is experienced with this equipment, for repair or warranty information, please contact: Manufacturer: Fire•Lite Alarms, Inc. One Fire-Lite Place Northford, CT 06472 (203) 484-7161 Product Model Number: MS-9200UDLS FCC Registration Number: US:1W6AL11B9200UDLS Ringer Equivalence: 1.1B...
Page 43: 3: Telephone Company Rights And Warnings
Telephone Requirements and Warnings Product Description 1.9.3 Telephone Company Rights and Warnings The telephone company, under certain circumstances, may temporarily discontinue services and/or make changes in its facilities, services, equipment or procedures which may affect the operation of this control panel. However, the telephone company is required to give advance notice of such changes or interruptions.
Page 44 Product Description Telephone Requirements and Warnings DOC Compliance - “This digital apparatus does not exceed the Class A limits for radio noise emis- sions from digital apparatus set out in the Radio Interference Regulations of the Canadian Depart- ment of Communications.” Representative: NOTIFIER/FIRE•LITE, CANADA 10 Whitmore Road Woodbridge, Ontario L4L 7Z4...
Page 45: Section 2: Installation
Section 2: Installation The cabinet may be either semi-flush or surface mounted. The cabinet mounts using two key slots and two 0.250” (6.35 mm) diameter holes located in the backbox. The key slots are located at the top of the backbox and the two securing holes at the bottom. Carefully unpack the system and check for shipping damage.
Page 46: Mounting Optional Transformer/Remounting Chassis
Installation Mounting Optional Transformer/Remounting Chassis 2.2 Mounting Optional Transformer/Remounting Chassis One XRM-24B(E) transformer is supplied standard with the control panel. An optional second XRM-24B(E) transformer can be ordered and installed to provide maximum system power. Note that the XRM-24B and XRM-24BE are only suitable for use with MS-9200UDLS(E) with a main circuit board assembly number 9200UDLS-PCX Rev Y, where “X”...
Page 47 Mounting Optional Transformer/Remounting Chassis Installation Semi-Flush Mounting Do not recess box more Hinge Slot for optional than 3.875” into wall to Dress Panel avoid covering venting holes on top of box. Mounting slots for optional Trim Ring Semi-flush mounting hole Hinge Slot for optional Dress Panel Figure 2.3 MS-9200UDLS Cabinet Mounting...
Page 48 Installation Mounting Optional Transformer/Remounting Chassis Figure 2.4 MS-9200UDLS Cabinet Dimensions An optional Trim Ring (P/N TR-CE-) is also available for semi-flush mount installations. MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 49: Power
Power Installation 2.3 Power WARNING: RISK OF EQUIPMENT DAMAGE AND PERSONAL INJURY SEVERAL DIFFERENT SOURCES OF POWER CAN BE CONNECTED TO THIS PANEL. DISCONNECT ALL SOURCES OF POWER BEFORE SERVICING. THE PANEL AND ASSOCIATED EQUIPMENT MAY BE DAMAGED BY REMOVING AND/OR INSERTING CARDS, MODULES OR INTERCONNECTING CABLES WHILE THIS UNIT IS ENERGIZED.
Page 50: 2: Battery Power
Installation Power 2.3.2 Battery Power The batteries must be sealed lead acid type. Before con- Interconnect Cable necting the batteries to the FACP, make certain that the interconnect cable between the batteries is not connected. Do not connect the interconnect cable until the system is completely installed.
Page 51: Relays
Relays Installation 2.4 Relays The FACP provides two programmable Form-C relays and one fixed fail-safe Form-C trouble relay, all with contacts rated for 2.0 amps @ 30 VDC (resistive) or 0.5 amps @ 30 VAC (resistive). Note that relay connections may be power-limited or nonpower-limited, provided that 0.25” spac- ing is maintained between conductors of power-limited and nonpower-limited circuits.
Page 52: 1: Style Y (Class B) Nac Wiring
Installation Notification Appliance Circuits 2.5.1 Style Y (Class B) NAC Wiring 4 Style Y (Class B) Notification Appliance Circuits, supervised and power-limited - 4.7 k, ½ watt P/N:71252 UL listed NAC 4 NAC 1 NAC 2 NAC 3 Polarized Bells Polarized Bells Polarized Strobes Polarized Strobes...
Page 53: Remote Synchronization Output
Remote Synchronization Output Installation 2.6 Remote Synchronization Output Synchronization is a feature that controls the activation of notification appliances in such a way that all devices will turn on and off at exactly the same time. This is particularly critical when activat- ing strobes which must be synchronized to avoid random activation and a potential hazard to indi- viduals.
Page 54: Ul Power-Limited Wiring Requirements
Installation UL Power-limited Wiring Requirements 2.7 UL Power-limited Wiring Requirements Power-limited and nonpower-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” (6.35 mm) away from any nonpower-lim- ited circuit wiring and nonpower-limited circuit wiring must enter and exit the cabinet through dif- ferent knockouts and/or conduits.
Page 55: Digital Communicator
Digital Communicator Installation 2.8 Digital Communicator Two independent telephone lines can be connected to the control panel. Telephone line con- trol/command is made possible via double line seizure as well as usage of an RJ31X style intercon- nection. Note that it is critical that the panel's digital communicator be located as the first device on the incoming telephone circuit to properly function.
Page 56: 1: Ferrite Clamp Installation
Installation Optional Module Installation 2.8.1 Ferrite Clamp Installation Per FCC requirements, ferrite clamps (supplied) are required on both phone lines. Apply one clamp per phone line inside the FACP cabinet as shown in Figures 2.11 and 2.13. To install, simply close the clamp around the phone line until it snaps shut.
Page 57 Optional Module Installation Installation Before installing the module, place the disconnect switch to the right (disconnect) position to pre- vent accidental activation of the municipal box. Note that a Disconnect LED will illuminate after the module is installed in the MS-9200UDLS. In addition, the System Trouble LED will turn on to indicate the Disconnect condition.
Page 58: 2: Printer
Installation Optional Module Installation TB10 Standoff Standoff NO NC C NC NO C Xmt Rcv Dtr Gnd B+ A+ B- A- A B Slc Slc Slc Slc Shield In+ In- Out+ Out- 4XTM J5 & J6 Connectors 4XTMF PH16 PH15 FACP main circuit board PRI.
Page 59: Printer Configuration
Optional Module Installation Installation Receive lines. Apply power to the FACP and printer or PC. Note that a ground fault (zero imped- ance to ground) may occur on the FACP, dependent on the printer or PC being used, due to this connection.
Page 60: Section 3: Programming
Section 3: Programming NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION AND OTHER INVOLVED PARTIES This product incorporates field-programmable software. In order for the product to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be limited to specific values or not used at all as indicated below: Program feature Permitted in...
Page 61: User Programming
User Programming Programming 3.2 User Programming The MS-9200UDLS is completely field programmable and requires no special software skills. While programming the MS-9200UDLS, the fire protection capabilities of the control panel are enabled. Site-specific programming may be accomplished in any of the following ways: •...
Page 62: Initial Power-Up
Programming Initial Power-up Exit Programming, Read Status The programmer can exit any mode by repeatedly pressing the keypad ESC (Escape) key until the display reads System All Normal. Note that the data which is entered during Programming mode is not saved until the programmer exits this mode by repeatedly pressing the ‘ESC’ key. If the Reset key is pressed or power is lost before exiting Programming mode, all data just entered will be lost.
Page 63 Programming and Passwords Programming to the first password character position. To exit Programming or Read Status mode at any time, press the ESC (Escape) key repeatedly. Note that Programming mode must be exited using the ESC key in order to store the program data entered during this mode. If the Reset key is pressed or power is lost before exiting Programming mode, the data just entered will not be saved.
Page 64: Master Programming Level
Programming Master Programming Level 3.6 Master Programming Level When the Master Program Level password is entered, the control panel will enter user Programming mode. In this mode, the piezo sounder remains off, the trouble relay is activated and the system Trouble LED flashes until Programming mode is exited. The following display will appear: PROGRAMMING 1=AUTOPROGRAM...
Page 65: 1=Autoprogram
Master Programming Level Programming 3.6.1 Autoprogram PROGRAMMING Pressing 1 while viewing Programming Screen #1, will select the Autoprogram option, which 1=AUTOPROGRAM prompts the control panel to poll all devices installed on the SLC loop. The primary purpose of 2=POINT PROGRAM 3=ZONE SETUP autoprogramming is to allow the installer a fast and easy way to bring the system on-line as quickly as possible.
Page 66: Detector Programming
Programming Master Programming Level Detector Programming Pressing 1, while viewing the Point Program Screen, will allow the programmer to add, delete or change the programming of an addressable detector. The following screen will be displayed by the control panel: DETECTOR 1=ADD 2=DELETE 3=EDIT...
Page 67: Delete Detector
Master Programming Level Programming Delete Detector  Pressing 2 in the Detector Screen will display the Delete Detector Screen which allows the DETECTOR 1=ADD programmer to delete a specific detector: 2=DELETE 3=EDIT DELETE DETECTOR Detector Screen ENTER DETECTOR# Delete Detector Screen A flashing cursor will appear in the position of the first asterisk to the left.
Page 68 Programming Master Programming Level If the selected address has been added to programming, device summary screens will be displayed. These screens allow the programmer to view all device settings at a single glance. Pressing the left or right arrow keys will allow the programmer to rapidly view the devices at the previous or next address (if installed).
Page 69: Enable/Disable Detector
Master Programming Level Programming The following examples show the editing of a photoelectric smoke detector with address 017, located on the SLC loop: EDIT DETECTOR 1D017 1=ENABLED 2=TYPE SMOKE(PHOTO) 3=VERIFICATION Edit Detector Screen #2 EDIT DETECTOR 1D017 1=WALKTEST 2=PAS 3=PRE-SIGNAL Edit Detector Screen #3 EDIT DETECTOR 1D017 1=ZONE ASSIGNMENT...
Page 70: Type
Programming Master Programming Level Type To select the type of detector being programmed, press the 2 key while viewing the Edit Detector EDIT DETECTOR 1=ENABLED Screen #2. This will cause the control panel to display the following Detector Type Screens: 2=TYPE 3=VERIFICATION DETECTOR TYPE...
Page 71: Walktest
Master Programming Level Programming Walktest The Walktest feature allows one person to test the system devices without the necessity of manually resetting the control panel after each device activation. To enable a device for the Walktest feature, EDIT DETECTOR 1=WALKTEST press 1 while viewing the Edit Detector Screen #3 until the display reads Walktest Yes.
Page 72: Zone Assignment
Programming Master Programming Level With the preceding program settings, when the detector with address 005 is activated, zone Z98 will cause its associated control module to activate immediately, sounding the connected signaling device to indicate the Pre-signal condition. Following the Pre-signal delay time, zone Z001 will cause its associated control module to activate and the control panel will initiate an alarm condition.
Page 73 Master Programming Level Programming Pressing 1 while viewing the Noun/Adjective Screen will cause the following screen(s) to be 1=STANDARD ADJECTIVE displayed. Note that the keyboard down arrow key must be pressed to see all the Adjective screens. 2=STANDARD NOUN Press the number corresponding to the adjective that is to be used as a descriptor for the location of 3=CUSTOM ADJECTIVE 4=CUSTOM NOUN the detector currently being programmed.
Page 74 Programming Master Programming Level Pressing 2 while viewing the Noun/Adjective Screen will cause the following screen(s) to be 1=STANDARD ADJECTIVE displayed. Note that the keyboard down arrow key must be pressed to see all the Noun screens. 2=STANDARD NOUN Press the number corresponding to the noun that is to be used as a descriptor for the location of the 3=CUSTOM ADJECTIVE 4=CUSTOM NOUN detector currently being programmed.
Page 75: Description
Master Programming Level Programming Pressing 3 or 4 while viewing the Noun/Adjective Screen will display screens similar to the 1=STANDARD ADJECTIVE previous Adjective and Noun Screens. The new screens will list custom Adjectives and Nouns 2=STANDARD NOUN which have been programmed into the control panel using the PS-Tools utility. These descriptors 3=CUSTOM ADJECTIVE 4=CUSTOM NOUN are selected as described in the previous sections.
Page 76: Module Programming
Programming Master Programming Level With the cursor on the first letter of the Noun field, press the zero key twice to recall the dis- play ROOM_304. The cursor automatically jumps from the first to the last letter of the Noun field With the cursor on the last letter of the Noun field, press the zero key again to increment the room number to 305...
Page 77: Add Module
Master Programming Level Programming Pressing 1 for Control Module or 2 for Monitor Module will cause the following screen to be displayed: ADD MODULE MODULE# IS ADDED Add Module Screen #3 The programmer can continue adding modules by pressing the ESC or left arrow key which will return the display to the Add Module Screen #1.
Page 78 Programming Master Programming Level A flashing cursor will appear in the position of the first asterisk to the left. The programmer keys in the three digit module address, such as 012. When the last digit is keyed-in, if the selected address has not been added to programming, a screen showing information about a device that is installed with a lower address, closest to the selected address, will be displayed.
Page 79: Enable/Disable Module
Master Programming Level Programming If the selected address corresponds to a monitor module, a screen displaying information about the module with the selected address will be displayed as illustrated in the following: NORMAL MONITOR <ADJ><NOUN> ZNNN 1M012 EDIT MONITOR 1M012 1=ENABLED 2=TYPE MONITOR...
Page 80: Type Monitor
Programming Master Programming Level Type Monitor EDIT MONITOR 1=ENABLED Using the PS-Tools Upload/Download utility program, unique user-defined monitor types can be 2=TYPE MONITOR created and loaded into the FACP for later use. The FACP response to the activation of a user- defined type is the same as most previous standard types in the list, thus allowing a variety of user- Edit Monitor Screen #2 defined types and responses.
Page 81 Master Programming Level Programming Monitor module type selection will affect the function of the point as follows: Monitor Type Action When Activated Pull-Station Fire Alarm User-Defined-1 same as previous (Pull-Station) Waterflow Fire Alarm Delayed User-Defined-2 same as previous (Waterflow) Monitor Fire Alarm User-Defined-3 same as previous (Monitor)
Page 82: Pre-Signal
Programming Master Programming Level Pre-signal EDIT MONITOR 1=PRE-SIGNAL To enable the Pre-signal feature, press 1 while viewing Edit Monitor Screen #3 until the display reads Pre-signal Yes. Each press of the 1 key will cause the display to toggle between Pre-signal Yes and Pre-signal No.
Page 83 Master Programming Level Programming Pressing 1 while viewing the Noun/Adjective Screen will cause the following screen(s) to be 1=STANDARD ADJECTIVE 2=STANDARD NOUN displayed. Note that the keyboard down arrow key must be pressed to see all the Adjective screens. 3=CUSTOM ADJECTIVE Press the number corresponding to the adjective that is to be used as a descriptor for the location of 4=CUSTOM NOUN the monitor module currently being programmed.
Page 84 Programming Master Programming Level Pressing 2 while viewing the Noun/Adjective Screen will cause the following screen(s) to be 1=STANDARD ADJECTIVE displayed. Note that the keyboard down arrow key must be pressed to see all the Noun screens. 2=STANDARD NOUN 3=CUSTOM ADJECTIVE Press the number corresponding to the noun that is to be used as a descriptor for the location of the 4=CUSTOM NOUN monitor module currently being programmed.
Page 85: Description
Master Programming Level Programming Description EDIT MONITOR 1=NOUN/ADJECTIVE The Description selection allows the programmer to enter additional information about the monitor 2=DESCRIPTION ***************** module currently being programmed. This information will be displayed as part of the device label on the LCD display. Pressing 2 while viewing Edit Monitor Screen #5 will cause the following Edit Monitor Screen #5 screen to be displayed: DESCRIPTION...
Page 86 Programming Master Programming Level Edit Module Screen for Control Modules  The programmer can change a module’s existing or factory default programming by pressing 3 in the Modules Screen. The following screen will be displayed: MODULES 1=ADD 2=DELETE 3=EDIT EDIT MODULE ENTER MODULE ADDRESS Modules Screen Edit Module Screen...
Page 87: Enable/Disable Module
Master Programming Level Programming To change the programming for the displayed module, press the keyboard down arrow key to view the following Edit Control screens: EDIT CONTROL 1=ENABLED 2=TYPE CONTROL 3=SILENCEABLE Edit Control Screen #2 EDIT CONTROL 1=WALKTEST 2=ZONE ASSIGNMENT 00 ** ** ** ** Edit Control Screen #3 EDIT CONTROL...
Page 88: Silenceable
Programming Master Programming Level While viewing one of the Control Type screens, select the type of control module being programmed by pressing the corresponding keypad number key. The display will return to the Edit Control Screen #2 and indicate the new type selection. NOTE: A control relay module set to the Resettable Power type will follow the main circuit board 24 VDC resettable power unless the control relay module is disabled.
Page 89: Zone Assignment
Master Programming Level Programming Zone Assignment A maximum of five zones can be programmed to each addressable control module. Pressing 2 while viewing Edit Control Screen #3 displays the following screen: ZONE ASSIGNMENT Z00 Z** Z** Z** Z** Zone Assignment Screen Note that Z** represents the Zone Number(s) corresponding to this device.
Page 90 Programming Master Programming Level Pressing 1 while viewing the Noun/Adjective Screen will cause the following screen(s) to be 1=STANDARD ADJECTIVE displayed. Note that the keyboard down arrow key must be pressed to see all the Adjective screens. 2=STANDARD NOUN 3=CUSTOM ADJECTIVE Press the number corresponding to the adjective that is to be used as a descriptor for the location of 4=CUSTOM NOUN the control module currently being programmed.
Page 91 Master Programming Level Programming Pressing 2 while viewing the Noun/Adjective Screen will cause the following screen(s) to be 1=STANDARD ADJECTIVE displayed. Note that the keyboard down arrow key must be pressed to see all the Noun screens. 2=STANDARD NOUN 3=CUSTOM ADJECTIVE Press the number corresponding to the noun that is to be used as a descriptor for the location of the 4=CUSTOM NOUN control module currently being programmed.
Page 92: Description
Programming Master Programming Level Description EDIT CONTROL 1=ADJECTIVE/NOUN The Description selection allows the programmer to enter additional information about the control 2=DESCRIPTION module currently being programmed. This information will be displayed as part of the device label on the display. Pressing 2 while viewing Edit Control Screen #4 will cause the following screen to Edit Control Screen #4 be displayed: DESCRIPTION...
Page 93: 3=Zone Setup
Master Programming Level Programming 3.6.3 Zone Setup Pressing 3 while viewing Programming Screen #2 will access the Zone Setup screens as illustrated PROGRAMMING 1=AUTOPROGRAM below: 2=POINT PROGRAM 3=ZONE SETUP ZONE SETUP Programming Screen #2 1=ENABLE 2=DISABLE 3=ZONE 97 98 99 Zone Setup Screen #1 ZONE SETUP 1=ZONES INSTALLED...
Page 94: Disable
Programming Master Programming Level Disable ZONE SETUP 1=ENABLE Pressing 2 for Disable, while viewing Zone Setup Screen #1, displays the following: 2=DISABLE 3=ZONE 97 98 99 ZONE TO DISABLE Zone Setup Screen #1 Disable Screen This screen allows the programmer to disable zones, one at a time. A flashing cursor appears next to the Z, prompting the programmer to enter a two digit zone number (01 - 99).
Page 95: Zones Installed
Master Programming Level Programming Zones Installed ZONE SETUP 1=ZONES INSTALLED Pressing 1 for Zones Installed, while viewing Zone Setup Screen #2, will display a screen similar to 2=ZONES ENABLED the following: 3=ZONES DISABLED Zone Setup Screen #2 ZONES INSTALLED 00 01 02 03 04 05 Zones Installed Screen This display will show all of the zones that have been programmed into the control panel.
Page 96: Zone Type
Programming Master Programming Level Zone Type ZONE SETUP 1=ZONE TYPES Zone Types must be programmed only if a DACT, programmed for zone reporting, is installed on 2=ZONES AVAILABLE 3=ZONE MESSAGE the control panel. Pressing 1 for Zone Types, while viewing Zone Setup Screen #3, will display a screen similar to the following: Zone Setup Screen #3 ZONE TYPE PROG...
Page 97: Zones Available
Master Programming Level Programming Zones Available ZONE SETUP 1=ZONE TYPES Pressing 2 while viewing Zone Setup Screen #3 will display the following screen: 2=ZONES AVAILABLE 3=ZONE MESSAGE ZONES AVAILABLE Zone Setup Screen #3 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 The display will show all of the zones that are still available for programming.
Page 98: Loop Protocol
Programming Master Programming Level Style 4 and Style 6. To program a system for Style 7 wiring, the programmer must select the Loop Setup for Style 6. Style 7 wiring is the same as Style 6 with the added requirement that each addressable device on the loop must have a pair of isolator modules, one on each side.
Page 99: Trouble Reminder
Master Programming Level Programming • Waterflow Silenceable: This option provides the ability to silence any output circuit activated by a monitor module programmed as a waterflow type. PROGRAMMING 1=LOOP SETUP Pressing 2 for System Setup, while viewing Programming Screen #2, will cause the following 2=SYSTEM SETUP screens to be displayed: 3=VERIFY LOOP...
Page 100 Programming Master Programming Level Pressing 1 while viewing the Banner Screen will select the blank factory default banner setting and BANNER display the following screen: 1=FACTORY 2=USER DEFINED FACTORY BANNER Banner Screen Factory Banner Screen Pressing the Enter key will store this selection in nonvolatile memory and return the display to the Banner Screen.
Page 101: Time-Date
Master Programming Level Programming Time-Date SYSTEM SETUP 1=TROUBLE REM The control panel time and date can be changed by pressing 3 while viewing the System Setup 2=BANNER Screen #1. The following screen will be displayed: 3=TIME-DATE System Setup Screen #1 TIME AND DATE 1=TIME 10:00 AM...
Page 102: Daylight Savings
Programming Master Programming Level digit is entered. After the last year digit is entered, the display will return to the Time-Date Screen which will show the new date entry. If an error is made while entering a digit, press the CLR key to delete the entire entry and beginning again.
Page 103: Timers
Master Programming Level Programming Timers SYSTEM SETUP 1=TIMERS Timer delays for PAS, Pre-signal and waterflow activation can be programmed by pressing 1 while 2=NAC viewing System Setup Screen #2. The following screen will be displayed: 3=RELAYS System Setup Screen #2 TIMERS 1=PAS DELAY 2=PRE SIGNAL...
Page 104: Waterflow Delay
Programming Master Programming Level A flashing cursor is positioned in the lower left corner of the display. Enter a delay time consisting of three digits, such as 009 for nine seconds. Upon entering the third digit, the time delay will be stored in the control panel memory and the display will return to the Delay Screen which will indicate the new delay time.
Page 105: Nac (Notification Appliance Circuit)
Master Programming Level Programming Pressing 2 while viewing AC Loss Delay Screen #1 will display the following: AC LOSS DELAY RANGE 00-23 AC Loss Delay Screen #2 A flashing cursor will appear in the lower left corner of the display. Type the two digit AC loss reporting delay in hours (00 to 23 hour delay).
Page 106 Programming Master Programming Level The following screens will be displayed for each selection: NAC # 1=ENABLED 2=TYPE BELL 3=SILENCEABLE NAC Screen #1 NAC # 1=AUTO SILENCE 2=CODING TEMPORAL NAC Screen #2 NAC # 1=ZONE 00 00 00 00 00 2=SIL INHIBITED NAC Screen #3 NAC # 1=SYNC TYPE...
Page 107 Master Programming Level Programming Type  NAC # 1=ENABLED The main circuit board NAC type can be programmed by pressing 2 while viewing NAC Screen #1. 2=TYPE The following screen will be displayed. Press the down arrow key to view additional screens: 3=SILENCEABLE NAC Screen #1 NAC TYPE...
Page 108: Auto Silence
Programming Master Programming Level Auto Silence  NAC # 1=AUTO SILENCE The Auto Silence feature, when enabled, automatically silences all main circuit board silenceable 2=CODING notification appliances after a programmed length of time. To enable this feature and program the TEMPORAL time delay before Auto Silence activation, press 1 while viewing NAC Screen #2.
Page 109 Master Programming Level Programming Coding (only for NACs not programmed as Sync Strobe Type)  The Coding feature allows the programmer to select the type of output that the main circuit board notification appliances will generate when activated. Pressing 2 while viewing NAC Screen #2 will cause the following displays to appear: CODING 1=STEADY...
Page 110 Programming Master Programming Level If another alarm point is activated and the countdown timer is counting, the alarm point will have no effect on the NACs unless the alarm point’s zones are directly mapped to one of the NACs, in which case it will follow the procedure outlined in step 2. If another alarm point is activated and the countdown timer has stopped counting due to the Acknowledge switch being pressed, the countdown timer will restart and the NACs will respond as outlined in step 2.
Page 111: Relays
Master Programming Level Programming Maximum Number of Strobes for Synchronization The total current draw for each Notification Appliance Circuit cannot exceed 2.5 amps. Refer to the manufacturer’s documentation supplied with the Strobes to determine the maximum current draw for each strobe and ensure that the circuit maximum is not exceeded. To ensure proper strobe and circuit operation, there is also a limit to the number of strobes that can be attached to each circuit.
Page 112: Canadian Option
Programming Master Programming Level While viewing the selected screen, press the number corresponding to the desired relay type to program the main circuit board relay. The choice will be stored in memory and the display will return to the Relay Type Screen which will show the programmed type choice. Press the Escape key to return to the Relays Selection Screen and repeat the preceding procedure for the remaining relays.
Page 113: 6: Verify Loop
Master Programming Level Programming 3.6.6 Verify Loop PROGRAMMING Pressing 3 while viewing Programming Screen #2, will select the Verify Loop option. During loop 1=LOOP SETUP verification, the FACP polls each device on the SLC to determine if the device is communicating 2=SYSTEM SETUP and whether or not it responds with the proper type identification.
Page 114: Erase History
Programming Master Programming Level Erase History The Erase History option allows a user to erase all events from the history file. This will provide a clean slate in order to use the history file to track future events. Pressing 2 while viewing the History Screen will display the following screen: ERASE HISTORY PROCEED ?
Page 115 Master Programming Level Programming From this screen, it is possible to view the walktest log, untested system points or a summary of the addressable devices tested during the current walktest. The user can select between any of these screens without interrupting the current walktest session. The walktest session will not end until the Unit In Walktest screen is exited by pressing the Escape key.
Page 116 Programming Master Programming Level To end the Walktest session, press the Escape key to return to the Walktest screen. Pressing 3 for View Results while viewing the Walktest screen, after a walktest session has been completed, will allow the operator to view the final results of the most recent walktest. The following screen will be displayed: WALKTEST RESULTS View Result Screen...
Page 117: 9: Option Modules
Master Programming Level Programming 3.6.9 Option Modules PROGRAMMING Options available for the MS-9200UDLS include ANN-BUS annunciators, legacy ACS BUS 1=HISTORY annunciators, and the LCD-80F Terminal Mode annunciator, printer connection for acquiring 2=WALKTEST hardcopy printouts of panel data, and PC (Personal Computer) connection for uploading and 3=OPTION MODULES downloading panel data.
Page 118 Programming Master Programming Level ACS Options  Pressing 2 for ACS Options while viewing the Annunciators screen, will display the following ANNUNCIATORS 1=TERM ENABLED screen: 2=ACS OPTIONS 3=ANN-BUS OPTIONS ACS OPTIONS Annunciator Screen 1=ACS ENABLED 2=ACS INSTALLED Pressing 1 while viewing the ACS Options screen will cause the display to toggle between ACS Enabled Yes and ACS Enabled No.
Page 119 Master Programming Level Programming Annunciator addressing is specific to the MS-9200UDLS control panel. The following table describes the annunciator addresses and the corresponding addressable devices that will be annunciated at each annunciator address. ACS Annunciator Address Annunciator Displays the Following Points 8 General System Status Points &...
Page 120 Programming Master Programming Level ANN-BUS Options  Pressing 3 for ANN-BUS Options, while viewing the Annunciators screen, will cause the following ANNUNCIATORS 1=TERM ENABLED screens to be displayed:. 2=ACS OPTIONS 3=ANN-BUS OPTIONS ANN-BUS SELECT Annunciators Screen #3 1=PRIMARY 2=SECONDARY 3=ANN-BUS OPTIONS ANN-BUS Select Screen A printer module, graphic annunciator module, LCD annunciator module, LED annunciator module and relay module can be programmed into the MS-9200UDLS system.
Page 121 Master Programming Level Programming Pressing the down arrow key will allow the programmer to view additional screens displaying Addresses 1-8. To select one or more addresses for the installed module(s), press the number key corresponding to the module address in each screen. The following screen will be displayed for each address: ANN-BUS MODULE X-1 ANN-BUS ADDRESS...
Page 122: Ann-I/O Options
Programming Master Programming Level If ANN-I/O, ANN-LED, or ANN-RLY is the selected module type, the following ANN-BUS Address Screen will be displayed: ANN-BUS MODULE X-1 ANN-BUS ADDRESS 1=TYPE ANN-I/O 2=MODULE OPTIONS ANN-BUS Address Screen Since the options for each of these module types can be individually set, pressing 2 for Module Options, while viewing the ANN-BUS Address Screen will display the available options as described below.
Page 123 Master Programming Level Programming ANN-I/O Zone Option  If Zone is selected as the module option, the first ten LEDs on the first ANN-I/O module will display the system status information. The remaining 30 LEDs on the first module and 40 LEDs on the remaining modules will display the active/alarm status of each zone in the Zone Range programmed for that particular module.
Page 124 Programming Master Programming Level ANN-I/O Point Option  If Point is selected as the module option, the first ten LEDs on the first ANN-I/O module will display the system status information. The remaining 30 LEDs on the first module and 40 LEDs on each additional module will display the active/alarm status of each point in the Point Range programmed for that particular module.
Page 125 Master Programming Level Programming ANN-LED Options  PRIMARY ANN-BUS 1=ENABLED Pressing 2 for Module Options while viewing the ANN-BUS Address Screen when the ANN-LED 2=MODULES INSTALLED option is selected, will display the following screen: 3=AUTO-CONFIGURE ANN-BUS Screen #2 ANN-LED - ADDR X-1 SLC 1 DET 1-10 ALARM, TBL, SUPV ANN-LED Address Screen #1...
Page 126 Programming Master Programming Level ANN-LED Zone Option - Alarm Only (for use with ANN-RLED module) If Zone is selected as the module option, and the module is programmed to annunciate alarms only, the first ten LEDs on the first ANN-LED module will display the system status information. The remaining 30 LEDs on the first module and the last 30 LEDs on the remaining modules will display the active/alarm status of each zone in the Zone Range programmed for that particular module.
Page 127 Master Programming Level Programming ANN-LED Zone Option - Alarm, Trouble and Supervisory If Zone is selected as the module option, and the module is programmed to annunciate alarms, troubles and supervisories, the first ten LEDs on the first ANN-LED module will display the system status information.
Page 128 Programming Master Programming Level ANN-LED Point Option - Alarm Only (for use with ANN-RLED module) If Point is selected as the module option and the module is programmed to annunciate alarms only, the first ten LEDs on the first ANN-LED module will display the system status information. The remaining 30 LEDs on the first module and the last 30 LEDs on each additional module will display the active/alarm status of each point in the Point Range programmed for that particular module.
Page 129 Master Programming Level Programming ANN-LED Point Option - Alarm, Trouble and Supervisory If Point is selected as the module option, and the module is programmed to annunciate alarms, troubles and supervisories, the first ten LEDs on the first ANN-LED module will display the system status information.
Page 130 Programming Master Programming Level ANN-RLY Options PRIMARY ANN-BUS 1=ENABLED Pressing 2 for Module Options while viewing the ANN-BUS Address Screen when the ANN-RLY 2=MODULES INSTALLED option is selected, will cause the following screen to be displayed: 3=AUTO-CONFIGURE ANN-BUS Screen #2 ANN-RLY - ADDR.
Page 131 Master Programming Level Programming ANN-BUS  ANN-BUS SELECT Pressing 3 for ANN-BUS Options, while viewing the ANN-BUS Select screen, will display the 1=PRIMARY following screen. 2=SECONDARY 3=ANN-BUS OPTIONS ANN-BUS Select Screen ANN-BUS 1=ANN-S/PG OPTIONS 2=FUTURE USE 3=ANN-80 OPTIONS ANN-BUS Options Screen ANN-BUS ANN-S/PG (Print) Options 1=ANN-S/PG OPTIONS...
Page 132 Programming Master Programming Level If the Parallel Port option is selected, the user has the ability to select an Offline Timer by pressing 3 while viewing Print Options screen #1. The resultant screen allows the programmer to program the Offline Timer for a delay of between 0 and 255 seconds before loss of printer supervision is reported as a trouble.
Page 133: Onboard Dact
Master Programming Level Programming The Silence Button Enable (SIL BTN ENABLE) option allows the programmer to select whether the Silence button on any installed ANN-80 annunciator will function normally or always be ignored. Pressing 1 while viewing the ANN-80 Options Screen #2 causes the display to toggle between Sil Btn Enable Yes (Silence button functions normally) and Sil Btn Enable No (Silence button never functions).
Page 134: On Board Dact
Programming Master Programming Level To select the type, press 1 while viewing the Primary Phone Line screen. The following screen will be displayed: PHONE LINE 1=TOUCHTONE 2=ROTARY 67/33 3=ROTARY 62/38 Primary Phone Type Screen Press 1 to select Touchtone dialing, 2 to select Rotary dialing with a make/break ratio of 67/33 or 3 to select Rotary dialing with a make/break ratio of 62/38.
Page 135: Ring Count
Master Programming Level Programming Pressing 1 while viewing On Board DACT Screen #2 will cause the following screen to appear: SERVICE TERMINAL 1=RING COUNT Service Terminal Screen SERVICE TERMINAL Ring Count 1=RING COUNT The ring count designates the number of rings allowed on the phone line prior to answering an incoming call from a service terminal.
Page 136 Programming Master Programming Level Central Station  Central Station programming configures the control panel DACT for contacting the central station. ON BOARD DACT 1=SERVICE TERMINAL Pressing 2 while viewing On Board DACT Screen #2 will cause the following screens to be 2=CENTRAL STATION displayed: 3=SUPERV PHONE LINE...
Page 137: Central Station Primary And Secondary Phone Numbers
Master Programming Level Programming To set the Trouble Call Limit, press 3 while viewing Central Station Screen #1. The following screen will be displayed. TROUBLE CALL LIMIT 00-99 RANGE Backup Reporting Screen Enter a value between 00 and 99, then press Enter to set the Call Limit to this value. NOTE: Entering a value of 00 will disable the Trouble Call Limit allowing the DACT to call the Central Station an unlimited number of times.
Page 138 Programming Master Programming Level Note that the following information must be entered for both the Primary and Secondary Central Station Phone Numbers. CENTRAL STATION # 1=TEST TIME INT 2=ACCOUNT CODE 0000 3=24HR TST TIME 0021 Primary/Secondary Screen #1 CENTRAL STATION 1=PHONE NUMBER Primary/Secondary Screen #2 CENTRAL STATION...
Page 139: Test Time Interval
Master Programming Level Programming Test Time Interval CENTRAL STATION Pressing 1 while viewing Primary/Secondary Screen #1 will cause the following screens to be 1=TEST TIME INT displayed: 2=ACCOUNT CODE 3=24HR TST TIME Primary/Secondary Screen #1 TEST TIME INTERVAL 1=24 HOURS 2=12 HOURS 3=8 HOURS Test Time Interval Screen #1...
Page 140: Phone Number
Programming Master Programming Level Use the 24 Hour Test Time screen to program the time that the DACT will transmit the 24 Hour Test to the Central Station. A flashing cursor will appear in the lower left corner of the screen. Enter a four digit number representing the test time using military time (0000 = midnight and 2359 = 11:59PM).
Page 141: Event Codes
Master Programming Level Programming Event Codes CENTRAL STATION Pressing 1 while viewing Primary/Secondary Screen #4 will cause the following screen to be 1=EVENT CODES displayed: EVENT CODES Primary/Secondary Screen #4 1=PULL STATION 2=MON-USER-DEF-1 3=WATERFLOW Event Code Screen Pressing the down arrow key allows viewing of all Events associated with the selected Communication Format.
Page 142: Ademco Contact Id & Sia Formats
Programming Master Programming Level Ademco Contact ID & SIA Formats The information shown in Table 3.11 is automatically programmed for the Central Station phone number Event Codes when the Ademco Contact ID or SIA Format is selected. Enter 0s for an Event Code Setting to disable the report.
Page 143 Master Programming Level Programming POINT_FAULT Zone Point POINT_DISABLE Zone Point AC_FAIL DRILL SLC 1 OPEN FAULT SLC 1 SHORT FAULT GROUND FAULT LOW BATTERY NO_BATTERY TELCO LINE 1 TELCO LINE 2 COMM FAULT 1 COMM FAULT 2 TOTAL COMM FLT PRINTER FAULT NAC 1 FAULT NAC 2 FAULT...
Page 144: Report Style
Programming Master Programming Level Report Style CENTRAL STATION Pressing 3 while viewing Central Station Screen #2 will cause the Report Style display to toggle 1=PRIMARY between Point and Zone. Setting the Report Style to Point will program the DACT to report 2=SECONDARY individual point status to the Central Station.
Page 145: 10: Password Change
Master Programming Level Programming The following screen will appear, which allows the programmer to select the baud rate for the printer communication: PRINTER BAUD RATE 1=2400 BAUD 2=4800 BAUD 3=9600 BAUD Printer Baud Rate Screen Pressing the number key corresponding to the desired baud rate (2 for 4800 Baud for example) will program the control panel for the selected baud rate and return the display to the Option Module Screen which will indicate Printer/PC PR4800 for a supervised printer installed at 4800 baud rate.
Page 146: 11: Clear Program
Programming Master Programming Level A flashing cursor will appear in the center of the display. Enter a new five digit password (such as 10101 for the Master Level). After the fifth digit is entered, the following screen will be displayed: VERIFY NEW PASSWORD Password Change Screen Re-enter the new password to accept the change.
Page 147: 12: Program Check
Master Programming Level Programming 3.6.12 Program Check PROGRAMMING The Program Check feature allows the programmer to view the zones which have been 1=PASSWORD CHANGE programmed to the Notification Appliance Circuits on the control panel but have not been 2=CLEAR PROGRAM programmed to Initiating Devices as well as other circuits with no input or output correlations.
Page 148: Maintenance Programming Level
Programming Maintenance Programming Level The Zone No Input screen allows the programmer to view the zones which have not been programmed to at least one input device (not including general alarm Zone 00). The example in the preceding screen indicates that Zones 05, 07, 09, 10 and 11 have been programmed to an addressable module (control module in this example) with an address of 001 on loop 1 but have not been programmed to any input devices.
Page 149: 1: Disable Point
Maintenance Programming Level Programming When the Maintenance level password (default 11111) is entered, the following screen will appear: PROGRAMMING 1=POINT PROGRAM 2=HISTORY 3=PROGRAM CHECK Note that in the preceding screens, an arrow appears to inform the programmer that additional options can be viewed by pressing the keypad down arrow key, as shown in the following screen. PROGRAMMING 1=WALKTEST 2=SYSTEM...
Page 150: 2=History
Programming Maintenance Programming Level A flashing cursor will appear in the bottom left corner of the display, prompting for the three digit device address. When the third digit is enter, 001 for example, a screen will appear which will allow enabling or disabling of the selected point, as illustrated in the following example: EDIT DETECTOR 1D001 1=ENABLED Enable/Disable Select Screen...
Page 151: 3=Program Check
Maintenance Programming Level Programming Pressing 2 while viewing the History Screen will cause the following screen to be displayed: ERASE HISTORY PROCEED ? 1=YES 2=NO Erase History Screen Pressing 1 while viewing the Erase History Screen will cause the message ERASING HISTORY, PLEASE WAIT to be displayed.
Page 152: 4: Walktest
Programming Maintenance Programming Level Pressing 2 while viewing the Program Check screen will display a screen similar to the following: ZONES NO INPUT 05 07 09 10 11 1M001 The Zone No Input screen allows the programmer to view the zones which have not been programmed to at least one input device (not including general alarm Zone 00).
Page 153 Maintenance Programming Level Programming The operator can press 1 to perform a silent walktest or 2 to perform an audible walktest. Pressing 1 or 2 will cause the control panel to enter Walktest Mode and will display the following screen: UNIT IN WALKTEST 1=VIEW WALKTEST LOG 2=VIEW POINTS...
Page 154: 5: System
Programming Maintenance Programming Level all untested points. If a point is tested while it is being displayed, the screen will update and display the next untested point. The first line indicates the total number of untested points. The second line displays information about an untested point.
Page 155: 6: Zone Setup
Maintenance Programming Level Programming To change the date, press 2 while viewing the Time and Date Screen. The following screen will be displayed: ENTER DATE MONTH DAY YEAR 01-01-2006 Date Screen A flashing cursor will appear on the left side of the display. Enter the two digit month, two digit day and four digit year.
Page 156 Programming Maintenance Programming Level Pressing 2 while viewing Zone Setup screen will display the following screen: ZONE TO DISABLE Disable Screen A flashing cursor appears to the right of the Z. To disable a zone, enter the two digit zone number (00 - 99).
Page 157 Notes MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 158: Section 4: Operating Instructions
Section 4: Operating Instructions 4.1 Panel Control Buttons 4.1.1 Acknowledge/Step The first press of the Acknowledge/Step key silences the piezo sounder, changes flashing LEDs to steady and also changes the status field on the LCD display from capital letters to small letters. When the piezo is silenced, an acknowledge message is sent to the printer and the history file.
Page 159 LED Indicators Operating Instructions Supervisory This is a yellow LED that flashes when one or more supervisory conditions occur, such as a sprinkler valve tamper condition. It illuminates steady when the Acknowledge/Step or Alarm Silence key is pressed. It turns off when the Reset key is pressed and remains off if all supervisory alarms have been cleared.
Page 160: Normal Operation
Operating Instructions Normal Operation 4.3 Normal Operation With no alarms or troubles in the system, the display message is System All Normal along with the current time and date as shown below. To set the time and date, refer to the appropriate section in this manual.
Page 161 Trouble Operation Operating Instructions The information displayed in the above example provides the following information: • First line in display: The type of event; in this example TROUBL indicating a device trouble  Device type identifier; in this example, SMOKE (PHOTO) indicates a Photoelectric smoke ...
Page 162: Alarm Operation
Operating Instructions Alarm Operation if the troubles were never acknowledged. Note that pressing the Alarm Silence key when only troubles exist in the system will have the same effect as pressing the Acknowledge/Step key except the Alarm Silenced LED will light. 4.5 Alarm Operation Alarm operation is similar to trouble operation with the following differences: •...
Page 163: Supervisory Operation
Supervisory Operation Operating Instructions Date; the current month, day and year in this example is 01 for January, 08 for the 8th day of  the month and 01 for the year 2001 Device Address; 1M001 in this example 1 represents SLC Loop, M represents a module and ...
Page 164: Hazard/Tornado Condition Operation
Operating Instructions Hazard/Tornado Condition Operation • Each ANN-LED can support up to 10 zones. Note that, like supervisories, process monitor signals latch (except when programmed for process monitor autoresettable) and can be assigned to software zones. 4.8 Hazard/Tornado Condition Operation Hazard/Tornado operation is intended for Manual activation.
Page 165: Nac Operation
NAC Operation Operating Instructions 4.10 NAC Operation There are four programmable NACs (Notification Appliance Circuits) resident on the MS-9200UDLS main circuit board. All NACs may be programmed as silenceable or nonsilenceable and may also be programmed for steady or coded operation. Coded operation provides a choice between March Time, Temporal or California coding.
Page 166: Time Functions: Real-Time Clock
Operating Instructions Time Functions: Real-Time Clock Smoke Detector Data Smoke detector data is monitored by the FACP, eliminating the need to test the sensitivity of each detector at its location. A printout of each detector’s data can be retrieved from the FACP using an optional printer or Windows HyperTerminal.
Page 167: Positive Alarm Sequence
Positive Alarm Sequence Operating Instructions onboard piezo sounds immediately  control panel LCD display will indicate a presignal event and the active point  control points programmed to Zone 98 will activate  annunciators (if enabled) will sound the local piezo, and pulse the alarm LED and zone LED ...
Page 168: Special System Timers
Operating Instructions Special System Timers 4.20 Special System Timers 4.20.1 Silence Inhibit Timer This option, if selected, prevents the Alarm Silence key from functioning for 60 seconds following an alarm. A new alarm during the initial 60 second period will not cause the timer to restart with a new 60 seconds.
Page 169: Walktest
Walktest Operating Instructions 13 sec. 0 sec. 73 sec. Detector Alarm Verification CONFIRMATION (60 seconds) RETARD (Retard + Confirmation) Alarm Ignored Control Panel Processes Alarm if Same Detector is Still in Alarm Detector Goes Into Alarm Control Panel Immediately Processes Alarm Different Detector Alarms During First Detector's Verification Period...
Page 170: 3=Power
Operating Instructions Read Status Read Status Entry When the operator presses the control panel key, the LCD will display the following: ENTER 1=READ STATUS MODE 2=PROGRAMMING MODE 3=REMOTE DOWNLOAD 4=MANUAL DIAL MODE Pressing 1, while this screen is being displayed, will cause the control panel to enter the Read Status mode which allows the user to view and print the programmed features and status of the control panel.
Page 171: 1: System Point
Read Status Operating Instructions 4.22.1 System Point READ STATUS Pressing 1 while viewing Read Status Screen #1 will cause the following screen to be displayed: 1=SYSTEM POINT 2=ZONES 3=POWER READ SYSTEM POINT Read Status Screen #1 SELECT TYPE 1=DETECTOR 2=MODULE The operator selects the type of device which is to be viewed by pressing 1 for Detector or 2 for Module.
Page 172: 2=Zones
Operating Instructions Read Status • Walktest Yes/No • PAS (Positive Alarm Sequence) Yes/No (for detectors only) • Pre-Signal Yes/No (for detectors and monitor modules) • Zone Assignments (five maximum) • Chamber Value • Adjective/Noun descriptor • Silenceable Yes/No (for control modules) 4.22.2 Zones READ STATUS Pressing 2 while viewing Read Status Screen #1 will cause the following screens to be displayed:...
Page 173 Read Status Operating Instructions 4.22.3 Power Pressing 3 while viewing Read Status Screen #1 will cause the following screens to be displayed: POWER BATTERY 27.21V 24 V RST 25.31 Power Screen #1 POWER CHARGER 28.36V NAC 1 -1.49V NAC 2 -1.49V Power Screen #2 POWER...
Page 174: 4: Trouble Reminder
Operating Instructions Read Status 4.22.4 Trouble Reminder READ STATUS Pressing 1 while viewing Read Status Screen #2 will display the following screen: 1=TROUBLE REMINDER 2=TIMERS 3=NAC Read Status Screen #2 TROUBLE REMINDER TROUBLE REM The screen indicates whether the Trouble Reminder feature is On or Off. 4.22.5 Timers Pressing 2 while viewing Read Status Screen #2 will cause the following Timer screens to be displayed:...
Page 175: 6: Nac
Read Status Operating Instructions 4.22.6 NAC Each NAC can be programmed individually with unique settings with the exception of Canadian Mode. When the Canadian Option is seletected in programming (see “Canadian Option” on page 112), all NAC settings are changed to that of NAC 1. While in Canadian Mode, if any NAC is setting is changed, all other NACs will get those same settings.
Page 176: 8: Program Check
Operating Instructions Read Status 4.22.8 Program Check Pressing 2 while viewing Read Status Screen #3 will cause a screen similar to the following to be displayed: PROGRAM CHECK 1=NACS NO INPUT 2=ZONES NO INPUT 3=ZONES NO OUTPUT Pressing 1 while viewing the Program Check screen will display a screen which will indicate if any input zones have not been programmed to one of the Notification Appliance Circuits.
Page 177: Acs Options
Read Status Operating Instructions The Annunciator Screen indicates if Terminal mode options are enabled or disabled. Pressing 2 for ACS Options while viewing the Annunciator Screen allows the operator to view the ACS Options screen: ACS OPTIONS ACS ENABLED 2=ACS ADDRESSES UDACT ENABLED ACS Options Screen The ACS Options screen indicates if the ACS option has been enabled YES or disabled NO.
Page 178: 11: Phone Line
Operating Instructions Read Status 4.22.11 Phone Line Pressing 2 while viewing Read Status Screen #4 will display the following screen: PHONE LINE PRIMARY TOUCHTONE SECONDARY TOUCHTONE 3=SUPERV PHONE LINE The second and third lines of this screen indicate that both the Primary and Secondary phone lines have been configured for touchtone dialing operation.
Page 179: 13: Service Terminal
Read Status Operating Instructions Central Station Screen #2 provides information on the Primary and Secondary Central Station programming which includes: • Test Time Interval • Account Code • 24 Hour Test Time • Phone Number • Communication Format • Event Codes 4.22.13 Service Terminal READ STATUS Pressing 1 while viewing Read Status Screen #5 will display the following screens:...
Page 180: 15: Print
Operating Instructions Read Status 4.22.15 Print READ STATUS To print program data or control panel status, press 3 while viewing Read Status Screen #5. The 1=FUTURE USE following screens will be displayed: 2=PRINTER/PC 3=PRINT Read Status Screen #5 PRINT 1=HISTORY 2=WALKTEST LOG 3=DETECTOR DATA Print Screen #1...
Page 181: Drift Compensation
Read Status Operating Instructions If the addressable smoke detector’s Chamber reading is not within the acceptable range, clean the detector and check the Chamber value again. If the reading is still not within the acceptable range, immediately replace the detector. Drift Compensation Drift compensation uses software algorithms that identify and compensate for long-term changes in the data readings from each addressable smoke detector.
Page 182: 16: Time-Date
Operating Instructions Read Status 4.22.16 Time-Date READ STATUS The operator can view the daylight savings time and the month and week when daylight savings 1=TIME-DATE time will begin and end. Pressing 1 while viewing Read Status Screen #6 will display the following screens: Read Status Screen #6 DAYLIGHT SAVINGS...
Page 183: Section 5: Central Station Communications
Section 5: Central Station Communications The control panel transmits zone and system status reports to Central Stations via the public switched telephone network. Two supervised telephone line connections are made to interface the control panel to the telephone lines. Two optional 7 foot telephone cords are available for this purpose and can be purchased separately.
Page 184: Transmittal Priorities
Central Station Communications Transmittal Priorities 5.1 Transmittal Priorities The integral communicator transmits highest priority events first. Events, in terms of priority, are listed below in descending order: Alarms (highest priority level) Pull stations  Waterflow  Smoke detector  Other alarm types ...
Page 185 Transmittal Priorities Central Station Communications The table below shows UL listed receivers which are compatible with the MS-9200UDLS. Format SIA-DCS-8        SIA-DCS-20        Ademco Contact ID   ...
Page 186: Section 6: Remote Site Upload/Download
Section 6: Remote Site Upload/Download Important! The FACP will automatically reset 2 minutes after completion of a user program download via the PS-Tools programming utility. To prevent program corruption, the operator must wait until this panel reset occurs before performing any panel operations. The control panel may be programmed or interrogated off-site via the public switched telephone network or locally using a USB cable.
Page 187: Transferring A Program
Transferring a Program Remote Site Upload/Download The Remote Download password (default 00000) must be entered to access the Remote Download feature. Note that the default password can be changed using the Password Change option (refer to “Password Change” on page 145). Entering the correct password will cause the following screen to be displayed: REMOTE DOWNLOAD 1=PROPRIETARY...
Page 188: 1: Security Features
Remote Site Upload/Download Transferring a Program 6.2.1 Security Features Upload and download with the control panel have been carefully designed to include key security features to ensure proper functionality. Any time a transfer is initiated, the control panel and the Service Terminal will communicate and transfer data before contacting a Central Station.
Page 189: Section 7: Power Supply Calculations
Section 7: Power Supply Calculations 7.1 Overview This section contains instructions and tables for calculating power supply currents in alarm and standby conditions. This is a four-step process, consisting of the following: Calculating the total amount of AC branch circuit current required to operate the system Calculating the worst-case system current load on the control panel, when primary (AC) power is applied, to assure that the limit of the its internal power supply will not be exceeded.
Page 190: 2: How To Calculate System Current Load
Power Supply Calculations Calculating the System Current Load All currents are given in amperes (A). Table 7.2 shows how to convert milliamperes and microamperes to full amperes. To convert... Multiply Example Milliamperes (mA) to mA x 0.001 3 mA x 0.001 = 0.003A amperes (A) µ...
Page 191 Calculating the System Current Load Power Supply Calculations Table 7.3 contains columns for calculating current load. For each column, calculate the current and enter the total (in amperes) in the bottom row. When finished, copy the totals from Calculation Column 2 and Calculation Column 3 to Table 7.4 on page 192. For maximum output current available per circuit and per panel, refer to Section 1.2, “Specifications”, on page 15.
Page 192: Calculating The Battery Size
Power Supply Calculations Calculating the Battery Size 7.4 Calculating the Battery Size Use Table 7.4 to calculate the total Standby and Alarm load in ampere hours (AH). This total load determines the battery size (in AH), required to support the system upon loss of primary (AC) power.
Page 193 Notes MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 194: Appendix A: Software Zones
Appendix A: Software Zones A.1 Correlations Setup and configuration of an addressable system is different than a conventional system. In a conventional system, assignment of input devices (smoke detectors, pull stations, heat detectors, etc.) to zones is accomplished through wiring. The wiring is direct from clearly marked panel terminals to any device assigned to a particular zone.
Page 195 Correlations Software Zones Correlation of Input and Output Zones Input Devices Zones Output Devices SD355 CMF-300 SD355 CMF-300 ZONE MMF-300 CMF-300 MMF-302 CMF-300 CMF-300 MMF-302 CMF-300 CP355 ZONE CMF-300 CP300 SD355 CMF-300 SD355 ZONE SD355 CMF-300 MMF-302 The zone correlations which are shown graphically above are also presented in Table A.1 on page 196 and Table A.2 on page 197.
Page 196 Software Zones Correlations DETECTOR ZONE ASSIGNMENT Device Zone Device Zone Address ADJ/NOUN Address ADJ/NOUN Type Number Type Number SD355 FIRST HALL SD355 ELEV. LOBBY CP355 2ND FLOOR CP355 ROOM 210 SD355 3RD FLOOR SD355 MEZZANINE SD355 MECH. ROOM Table A.1 Detector Programming Sheet Example MS-9200UDLS/E/C Manual —...
Page 197 Correlations Software Zones MONITOR/CONTROL MODULE ZONE ASSIGNMENT Device Zone Device Zone Address ADJ/NOUN Address ADJ/NOUN Type Number Type Number MMF-300 MMF-302 1, 2 MMF-302 1, 2 MMF-302 CMF-300 CMF-300 CMF-300 CMF-300 CMF-300 1, 2, 3 CMF-300 Table A.2 Module Programming Sheet Example MS-9200UDLS/E/C Manual —...
Page 198 Software Zones Correlations DETECTOR ZONE ASSIGNMENT Device Zone Device Zone Address ADJ/NOUN Address ADJ/NOUN Type Number Type Number Table A.3 Blank Detector Programming Sheet MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 199 Correlations Software Zones MONITOR/CONTROL MODULE ZONE ASSIGNMENT Device Zone Device Zone Address ADJ/NOUN Address ADJ/NOUN Type Number Type Number Table A.4 Blank Module Programming Sheet MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 200: Appendix B: Default Programming
Appendix B: Default Programming The following table provides a list of the programming options and their factory default settings. Program Option Factory Default Program Option Factory Default Detector Programming Not Installed Relay 1 Alarm Detector Type Smoke-Photo Relay 2 Trouble (fixed) Detector Verification Relay 3 Supervisory...
Page 201: Appendix C: Nfpa Standard-Specific Requirements
Appendix C: NFPA Standard-Specific Requirements The MS-9200UDLS has been designed for use in commercial, industrial, and institutional applications and meets the requirements for service under the National Fire Protection Association (NFPA) Standards outlined in this Appendix. The minimum system components required for compliance with the appropriate NFPA standard are listed below: MS-9200UDLS Control Panel Contains the main control board, cabinet (backbox and door), main power supply transformer and...
Page 202 NFPA Standard-Specific Requirements NFPA 72 Auxiliary Fire Alarm System All connections are power-limited and supervised. This application is not suitable for separate transmission of sprinkler supervisory or trouble conditions. Notes: 3 ohms maximum loop resistance allowed for wiring from control panel to Municipal Box. Cut JP3 on the MS-9200UDLS main circuit board to supervise placement of 4XTMF module and circuit.
Page 203 NFPA Standard-Specific Requirements NFPA 72 Remote Station Protective Signaling System Notes: Cut Jumper JP3 on the MS-9200UDLS main circuit board to supervise placement of the 4XTMF module. Refer to “4XTMF Transmitter Module Installation” on page 56 for detailed information. RS82 Remote Station Receiver UL listed. Refer to Instruction Manual for Remote Station Receiver Model RS82.
Page 204 NFPA Standard-Specific Requirements NFPA 72 Proprietary Protective Signaling Systems MS-9200UDLS Addressable Fire Control Panel MS-9200UDLS Main Board Form-C Alarm contact programmed to activate on General Alarm. Form-C Trouble contact which will automatically activate on any Trouble condition. Form-C relay contact programmed to activate on Supervisory condition.
Page 205: C.1: Central Station/Remote Station Transmitter: Connection To Facp Dry Contacts
Central Station/Remote Station Transmitter: Connection to FACP Dry Contacts NFPA Standard-Specific Requirements C.1 Central Station/Remote Station Transmitter: Connection to FACP Dry Contacts The dry contacts of the FACP programmable relays can be used to trip a UL-864 Listed Central Station/Remote Station Transmitter. The FACP contacts must be supervised by the Central Station/Remote Station Transmitter module using End-of-Line Resistors (ELRs) with a value determined by the Transmitter manufacturer.
Page 206: C.2: Mbt-1 Municipal Box Trip - Silenceable
NFPA Standard-Specific Requirements MBT-1 Municipal Box Trip - Silenceable C.2 MBT-1 Municipal Box Trip - Silenceable The following figure illustrates the connection of the MBT-1 (Municipal Box Trip) between the FACP and a Local Energy Municipal Box. The use of an addressable control module programmed for General Alarm and Silenceable allows silencing of the Municipal Box without resetting the panel or box.
Page 207: Appendix D: Facp With Keltron
Appendix D: FACP with Keltron The following figure illustrates the connections between the FACP and Keltron Receiver/Transmitter. CAUTION: POSSIBLE EQUIPEMENT DAMAGE FOR REASONS OF WIRING DIAGRAM CLARITY, TERMINAL DESIGNATIONS OF KELTRON MODULES ARE NOT SHOWN IN ACTUAL ORDER. FOLLOW KELTRON MANUAL AND MODULE MARKINGS FOR EXACT TERMINAL LOCATIONS TO PREVENT SEVERE MODULE DAMAGE! IMPORTANT! All connections between the FACP and Keltron modules must be made within 20...
Page 208: Appendix E: Wire Requirements
Appendix E: Wire Requirements T-tapping of the SLC loop wiring is allowed for 2-wire (Style 4) configurations. The total resistance of any branch cannot exceed 40 ohms. The total wire length of all branches cannot exceed 10,000 feet (3,000 m). Connecting external system accessories to the MS-9200UDLS main circuits must be carefully considered to ensure proper operation.
Page 209 Wire Requirements CIRCUIT CONNECTIONS WIRE REQUIREMENTS Recommended Wire Type and Circuit Type Circuit Function Max. Distance Wire Gauge and Compatible Brands Limitations Feet (meters) SLC loop Connects to Twisted, shielded pair 10,000 (3,000 m) 12 AWG (3.25 mm ): Genesis 4410, (power-limited) Addressable 40 ohms maximum per...
Page 210: E.1: Nac Wiring
Wire Requirements NAC Wiring E.1 NAC Wiring The following table lists NAC wiring requirements for the FACP. NAC Load Max. CLASS-B CLASS-A (Amps) allowable Max. allowable wire pair length Max. allowable wire pair length total loop (feet) (feet) resistance AWG 12 AWG 14 AWG 16 AWG 18...
Page 211: Appendix F: Hvac Control
Appendix F: HVAC Control The FACP can be programmed to shut down a building’s HVAC fans in the event of a fire. The fans cannot be restarted until the fire alarm condition has been cleared and the FACP has been reset to a normal (non-alarm) condition.
Page 212: F.2.2: Hvac Ovrride
HVAC Control Monitor Module Operation F.2.2 HVAC OVRRIDE The HVAC OVRRIDE type code can be assigned to any addressable monitor module for the purpose of overriding or preventing the HVAC SHUTDN control modules from activating. The HVAC OVRRIDE monitor module acts globally throughout the FACP system and therefore is not programmed to a particular software zone.
Page 213: Appendix G: Ademco Contact Id Format Event Code Descriptions
Appendix G: Ademco Contact ID Format Event Code Descriptions This appendix describes the various Event Codes and their messages which are available for the Ademco Contact ID Format. G.1 Transmission Format Between DACT and Receiver The transmission string for the Ademco Contact ID Format is as follows: SSSS 18 QXYZ GG CCC where SSSS Four digit Subscriber ID Account Code...
Page 214: Event Code Classifications
Ademco Contact ID Format Event Code Descriptions Ademco Contact ID Typical Printout EVENT CODE CLASSIFICATIONS ALARMS SUPERVISORY TROUBLES OPEN/CLOSE DISABLES/BY TEST/MISC. REMOTE ACCESS PASSES Medical Fire System Open/Close System Test Fire Sounder/Relay Remote Access Sounder/Relay Panic System Peripheral Access Control System Peripheral Burglary Communication...
Page 215 Ademco Contact ID Typical Printout Ademco Contact ID Format Event Code Descriptions EVENT MESSAGE 151 Gas detected ALARM - Gas Detected - # 152 Refrigeration ALARM - Refrigeration - # 153 Loss of heat ALARM - Heating System - # 154 Water leakage ALARM - Water Leakage - # 155 Foil break...
Page 216 Ademco Contact ID Format Event Code Descriptions Ademco Contact ID Typical Printout EVENT MESSAGE Protection Loop Troubles - 370 370 Protection loop TROUBLE - Protection Loop - # 371 Protection loop open TROUBLE - Protection Loop Open - # 372 Protection loop short TROUBLE - Protection Loop Short - # 373 Fire trouble TROUBLE - Fire Loop - #...
Page 217 Ademco Contact ID Typical Printout Ademco Contact ID Format Event Code Descriptions EVENT MESSAGE Test Misc. - 600 601 Manual trigger test TEST - Manually Triggered (restore not applicable) 602 Periodic test report TEST - Periodic (restore not applicable) 603 Periodic RF transmission TEST - Periodic Radio (restore not applicable) 604 Fire test TEST - Fire Test (restore not used)
Page 218: Appendix H: Central Station Points
Appendix H: Central Station Points The control panel transmits Central Station Reports in a numerical format which indicates the FACP addressable device address that is reporting. The following table indicates the Central Station Report (CS Report) number that will be transmitted and the addressable device address it represents.
Page 219 Central Station Points Module Module Module Module Report Address Report Address Report Address Report Address Table H.2 Addressable MODULES MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 220: Appendix I: Canadian Application
Appendix I: Canadian Application • The MS-9200UDLSC is supplied with the DP-9692 Dress Panel. • When installing and programming the FACP, the Canadian Option must be set to ON prior to any other panel programming (refer to “Canadian Option” on page 112 of the Programming Section of this manual).
Page 221 Canadian Application Optional Secondary ANN-BUS (data on connector TB8, power on TB1 Terminals 3&4 with JP6 pins 1&2 jumpered) Primary ANN-BUS (data on connector TB9, power on TB1 Terminals 1&2) ANN-LED in metal conduit (adjacent to FACP) ANN-80C FACP ANN-I/O ANN-S/PG ANN-RLY ANN-LEDs...
Page 222 Canadian Application Notes: TB10- 1. The CRF-300 and the MMF-300 SLC Loop must be mapped to the same zone MMF-300* Output which is programmed for supervisory operation. 2. No other device can be mapped to that supervisory zone. 3. Wire gauge must be 18AWG minimum.
Page 223 Notes MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010...
Page 224: Index
Index Numerics Alarm 162 Alarm Silence 18 24 Hour Test Time 139 alarm verification 14 300 Series addressable devices 20 ANN-80 Annunciator Module 14 4XTMF module 202 ANN-80C Indicator Module 14 coil resistance 56 ANN-BUS 39 current 56 guidelines 22 installation 56 power 25 installation steps 57...
Page 225 Index C–E see also battery box 19 DACT enable 133 onboard 133 cabinet data dimensions 47 see also detector data and sensitivity 166 cabinet mounting 45 Data Entry Calculate System Current Draw 190 via computer keyboard 60 Calculating the Battery Size 192 via keypad 60 Canadian Applications 43 data values...
Page 226 F–M Index detector 67 LCD-80FC 15 detector screens 68 Indicators 17 module, monitor 77 Installation 45 EIA-232 58 intelligent 13 for PC/Printer connection 16 Internet Protocol DACT 22 see also Printer/PC interface 14 Inventory 13 EIA-485 INVREP 181 for ACS annunciators 16 IPDACT 22 for LCD-80F 16 Enable 93...
Page 227 Index N–P enable/disable 79 Normal 160 see also addressable modules 19 normal display 61 Module Programming 76 Notification Appliance Circuit 15 Monitor module 19 see also NAC 13 adjective 83 Noun enable/disable 79 list 74 noun 84 monitor module 84 noun/adjective 82 multiple entries 75 type 80...
Page 228 R–S Index power supply calculations 189 power-limited Read Status 61 relay connections 51 annunciators 176 Power-up exiting 62 first time 62 history 176 Pre-signal 14 NAC 175 function 166 power 173 selection 82 Print 180 Pre-signal Delay timer 103 printer/PC 179 Pre-signal timer 103 program check 176 primary ANN- BUS 16...
Page 229 Index T–V Security Features 188 programming 110 sensitivity 166 see also strobe synchronization 14 see also smoke detector sensitivity 166 synchronized 166 Service Terminal 134 synchronized signals 166 Signal rate 14 and silenceable circuits 107 Signaling Line Circuit System see also SLC 15 Maintenance Level 154 Silence Inhibit 14 System Point 171...
Page 230 W–Z Index voltage measurements 173 ranges 173 Walktest 14 audible 114 Maintenance Level 152 operation 169 selection 82 silent 114 waterflow nonsilenceable 96 silenceable 96 Waterflow Delay timer 103 Waterflow Retard Timer 168 Waterflow Silenceable 99 Wire Requirements 208 wiring AC Power 49 earth ground 49 NAC Style Y 52...
Page 231 Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
Page 232 World Headquarters 1 Firelite Place Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.firelite.com...

This manual is also suitable for:

Ms-9200udlse Ms-9200udlsc

Fire-Lite MS-9200UDLS Manual

Section 1: Product Description

Section 2: Installation

Section 3: Programming

Section 4: Operating Instructions

Section 5: Central Station Communications

Section 6: Remote Site Upload/Download

Section 7: Power Supply Calculations

Appendix A: Software Zones

Appendix B: Default Programming

Appendix C: NFPA Standard-Specific Requirements

Appendix D: FACP with Keltron

Appendix E: Wire Requirements

Appendix F: HVAC Control

Appendix G: Ademco Contact ID Format Event Code Descriptions

Appendix H: Central Station Points

Appendix I: Canadian Application

Index

Quick Links

Related Manuals for Fire-Lite MS-9200UDLS

Summary of Contents for Fire-Lite MS-9200UDLS
