- Page 1 BG60TCBL/BG60TCSS/BG60TCW 60 cm 4 Burner gas hob with thermocouples BT62TCSS 60 cm 4 Burner gas hob with thermocouples B68TCSS 70 cm 5 Burner gas hob with thermocouples...
- Page 2 User Manual for your Baumatic BG60TCBL/BG60TCSS/BG60TCW 60 cm 4 Burner gas hob with thermocouples BT62TCSS 60 cm 4 Burner gas hob with thermocouples B68TCSS 70 cm 5 Burner gas hob with thermocouples NOTE : This User Instruction Manual contains important information, including safety &...
-
Page 3: Table Of Contents
Contents Environmental note Important safety information 5 – 7 Specifications 8 – 12 BG60TCBL/SS/W BT62TCSS B68TCSS Electrical details Gas details Gas hob surface layout Using the gas hob 13 - 15 Before first use Switching the hob on Push button ignition with flame failure safety device 13 –... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
No modifications to the appliance are permitted by Baumatic Ltd. o You should not store or place flammable or highly flammable liquids/materials on top of or near the appliance. Items made... - Page 6 Safety o Baumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowe to touch the applianc e at any time. During and after use, all surfaces will be hot. o If it is necessary for younger family members to be in the...
- Page 7 If the appliance is being used in a Leisure Accommodation Vehicle, the requirements of N 721 MUST be followed. o Baumatic Ltd. DO NOT recommend that this appliance is installed on any type of marine vessel. Declaration of conformity This appliance complies with the following European Directives: -73/23/EEC dated 19/02/1973 Low Voltage Directive.
-
Page 8: Specifications
Specifications BG60TCBL/SS/W Product dimensions: Aperture dimensions: Height: 500 mm Height: 480 mm Width: 585 mm Width: 560 mm Depth: 35 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o Side control operation o Push button ignition o Enamelled pan stands... -
Page 9: Bt62Tcss
BT62TCSS Product dimensions: Aperture dimensions: Height: 500 mm Height: 480 mm Width: 585 mm Width: 560 mm Depth: 35 mm Product specifications: o 1 x 3.30 kW wok burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o Front control operation o Automatic ignition o Heavy duty cast iron pan stands... -
Page 10: B68Tcss
B68TCSS Product dimensions: Aperture dimensions: Height: 510 mm Height: 480 mm Width: 685 mm Width: 560 mm Depth: 35 mm Product specifications: o 1 x 3.30 kW wok burner o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o Front control operation o Automatic ignition... -
Page 11: Electrical Details
Electrical details Rated Voltage: 230 Vac 50 Hz Supply Connection: 3 A (double pole switched fused outlet with 3mm contact gap) Max Rated Inputs: 0.008 to 0.02 kW (depending on model) Mains Supply Lead: 3 core x 0.75mm² Gas details Connection: Rp ½... -
Page 12: Gas Hob Surface Layout
Gas hob surface layout BG60TCBL/SS/W BT62TCSS B68TCSS... -
Page 13: Using The Gas Hob
Using the gas hob Before first use IMPORTANT: You should clean the hob surface (see “Cleaning and maintenance” section). Switching the hob on The following symbols will appear on the control panel, next to each control knob: 0 = gas off Large flame: maximum setting Small flame: minimum setting o The minimum setting is at the end of the anti-clockwise rotation... -
Page 14: Automatic Ignition With Flame Failure Safety Device
o After this 20 second interval, turn the control knob to your required setting between the maximum and minimum setting symbols. o To turn the burner off, turn the control knob fully clockwise to the gas off position. o In case of power failure, the burners can be lit by carefully using a match. -
Page 15: Energy Saving Tips
Energy saving tips BURNERS PANS Minimum Maximum diametre diametre 220 mm 260 mm Rapid 180 mm 220 mm Semi-rapid 120 mm 200 mm Auxiliary 80 mm 160 mm o The diametre of the bottom of the pan should correspond to that of the burner. -
Page 16: Cleaning
Cleaning Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. Cleaning the hob top Any residues that are left on the hob top surface from cleaning agents will damage it. -
Page 17: Maintaining Cast Iron Pan Stands (Bt62Tcss/B68Tcss)
IEE Wiring Regulations o Electricity at Work Regulations BS 6172 o Installation of Domestic Gas Cooking Appliances (if necessary, BS 5482 Installation of Domestic LPG Appliances) o BS 5440 Installation of Flues and Ventilation for Gas Appliances o Baumatic Ltd Installation Instructions... -
Page 18: Positioning
Positioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use. o This appliance can be located in a kitchen, a kitchen diner or a bed sitting room. -
Page 19: Unpacking The Appliance
Unpacking the appliance When unpacking the appliance please check that the following items are contained within the packaging: 1 x Baumatic hob 1 x Baumatic guarantee card 2 x Pan stands 4 x Fixing screws 3 x Pan stands (B68TCSS) - Page 20 o Cut a hole in the worktop that corresponds with the drawings shown on page 19. o IMPORTANT: You must have a gap of at least 25 mm between the underneath of the appliance and any surface that is below it. o Carefully turn the hob upside down and place it on a cushioned mat.
-
Page 21: Gas Connection
Conversion for use on LPG and other gases must only be undertaken by a qualified person. For information on the use of other gases, please contact the Baumatic Advice Line. o The cooker must be installed by a qualified person, in... -
Page 22: Ventilation Requirements
Ventilation requirements o The room containing the hob should have an air supply in accordance with the current edition of BS 5440: Part 2: o The room must have opening windows or equivalent; some rooms may also require a permanent vent. o If the room has a volume between 5 and 10m³, it will require an air vent of 50cm²... -
Page 23: Gas Safety (Installation And Use) Regulations
Gas Safety (Installation and Use) Regulations IMPORTANT: The appliance MUST be connected to the gas supply by use of a ½ BSP Elbow, seal, copper pipe and an isolation tap fitted in an easily accessible position. o It is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety Installation and Use Regulations. -
Page 24: Gas Adjustment (Conversion To Lpg)
Gas adjustment (Conversion to LPG) All work must be carried out by a CORGI registered engineer. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. o Remove the pan-stands, burners and flame spreaders (A). -
Page 25: Minimum Flow Adjustment For Hob Gas Taps
o IMPORTANT: The minimum flow adjustment process must be completed before the appliance is next used. Minimum flow adjustment for hob gas taps. All work must be carried out by a CORGI registered engineer. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. -
Page 26: Gas Tap Maintenance
Gas tap maintenance These maintenance operations MUST ONLY be carried out by a CORGI registered engineer. IMPORTANT: Before carrying out any maintenance operations, disconnect the appliance from the gas and electricity supplies. If a gas tap becomes stiff to operate, then you should proceed as follows: o Remove the control knobs, pan supports, burners, hob fixing screws and clamps. -
Page 27: Electrical Connection
Replacing the mains supply cable If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained from the Baumatic Spares Department. The mains supply cable should be replaced in accordance with the following instructions: o Switch the appliance off at the control switch. -
Page 28: My Appliance Isn't Working Correctly
Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the... -
Page 29: Contact Details
Czech Republic United Kingdom Baumatic CR spol s.r.o. Baumatic Ltd., Amperova 495 Baumatic Buildings, 46215, Librec 6 Bennet Road, Czech Republic Reading, Berkshire RG2 0QX +420 800 185 263 United Kingdom www.baumatic.cz Sales Telephone (0118) 933 6900 Slovak Republic Sales Fax Baumatic Slovakia, s.r.o.
