- Page 1 Instructions for the installation and advice for the maintenance MODEL: BGH60 Instructions Manual MODEL: BGH60 PLEASE READ THIS MANUAL BEFORE INSTALLING THE HOTPLATE. COD:01099HS - 31.07.2012...
- Page 2 Dear Customer, Congratulations on purchasing your new product from Think Appliances. To register your parts and labour warranty (some conditions apply please refer to your warranty card for more details) please contact out Customer Care team on: 1800 444 357 Our Customer Care centre is there to ensure you get the most out of your appliance.
- Page 3 DESCRIPTION OF THE HOT PLATES MODEL: BGH60 Natural U-LPG Rapid gas burner 12.0 MJ 10.4 MJ Semi-rapid gas burner 7.1 MJ 6.2 MJ Auxiliary gas burner 4.1 MJ 3.5 MJ Trivet 2 burner Burner 3 control knob Burner 1 control knob...
- Page 4 1) BURNERS the reduced rate position (small flame fig. 1). - Always place a lid on the pans. A diagram is screen-printed above each knob on the front panel. This diagram indicates to which Burners Power ratings Pan Ø in cm burner the knob in question corresponds.
- Page 5 Notes: Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig. 4 and fig. 5). Intensive and lengthy use of the appliance may require additional ventilation.
-
Page 6: Care And Maintenance
CLEANING IMPORTANT: CARE & MAINTENANCE Always disconnect the appliance from the gas To optimize the appearance and up keep of and electricity mains before carrying out any stainless steel: cleaning operation. 1) ALWAYS keep stainless steel out of contact from acid/acid based solvent (liquid or vapour form). -
Page 7: Installation
INSTALLATION TECHNICAL INFORMATION Any adjoining wall surface situated within 200 mm FOR THE INSTALLER from the edge of any hob burner must be a suitable non-combustible material for a height of 150 mm for This appliance shall be installed only by authorised personnel and in accordance with the entire length of the hob. -
Page 8: Gas Connection
INSTALLATION 5) GAS CONNECTION Liquified Petroleum Gas In a LPG installation the gas regulation is made at The gas connection is located in the rear and on the the gas cylinder and regulation at the appliance is underside of the appliance 100 mm from the right not required. -
Page 9: Electrical Connection
INSTALLATION 6) ELECTRICAL CONNECTION - The power supply cable must be positioned so that no part of it is able to reach an overtemperature of 75 K. IMPORTANT: the appliance must be - Never use reductions, adapters of shunts for installed following the manufacturer's connection since these could create false contacts and lead to dangerous overheating. - Page 10 ADJUSTMENTS 7) TAPS Always disconnect the appliance from the electricity main before making any adjustments. Our taps are suitable for all gas, they are male All seals must be replaced by the technician at conical type. the end of any adjustments or regulations. “Reduced rate”...
- Page 11 Appliance models: Gas stainless steel hotplate Appliance models: Gas stainless steel hotplate models: models: BGH60 BGH60 1. Remove each burner cap and burner skirt. 1. Remove each burner cap and burner skirt. 2. Remove the U-LPG main injector with a 7 2.
-
Page 12: Replacing The Injectors
CONVERSIONS 10) REPLACING THE INJECTORS affix the label corresponding to the new gas regulation on the appliance instead of the already The burners can be adapted to different types of gas existing one. This label is supplied in the packet by installing injectors suited to the type of gas containing the spare injectors. - Page 13 SERVICING Always turn off the electrical ignition before Greasing the taps (see fig. 17 - 18) proceeding with any servicing operation. If a tap becomes stiff to operate, it must be Servicing should be carried out only by immediately greased in compliance with the authorised personnel.
- Page 14 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE HOT PLATE CABLE POWER SUPPLY H05 RR - F Section 3 X 0.75 mm Gas hot plate ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
-
Page 15: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS Before leaving the factory, this appliance will have been tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention. - Page 16 ! "# $ $ # %& ' (% ' ) * + %! , ' %! % &...
