User Manual for your
BGHU600SS / BGHU610SS
60 cm 4 Burner gas hob
BGHU700SS
70 cm 5 Burner gas hob
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
JW 23/04/13
Advertisement
Table of Contents
Related Manuals for Baumatic BGHU600SS
Summary of Contents for Baumatic BGHU600SS
- Page 1 User Manual for your BGHU600SS / BGHU610SS 60 cm 4 Burner gas hob BGHU700SS 70 cm 5 Burner gas hob NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 2: Table Of Contents
Contents Environmental note Important safety information 5 – 7 Specifications 8 – 13 BGHU600SS BGHU610SS BGHU700SS Electrical details Gas details Gas hob surface layout Using the gas hob 13 - 15 Before first use Switching the hob on Automatic ignition with flame failure device... -
Page 3: Environmental Note
Environmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact Customer Services. - Page 5 Child Safety o The manufacturer strongly recommends that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. During and after use, all surfaces will be hot. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 6 Cleaning o Cleaning of the hob should be carried out on a regular basis. o IMPORTANT: Before attempting to clean the appliance, it should be disconnected from the mains and cool. o Great care should be taken whilst using this appliance and when following the cleaning procedure.
-
Page 7: Specifications
Specifications BGHU600SS Product dimensions: Depth: 510 mm Width: 600 mm Height: 40 mm Aperture dimensions: Depth: 480 mm Width: 560 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner... -
Page 8: Bghu610Ss
BGHU610SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 600 mm Width: 560 mm Height: 40 mm Product specifications: o 1 x 3.80 kW triple crown (wok) burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o Front control operation o Automatic ignition o Heavy duty cast iron pan stands... -
Page 9: Bghu700Ss
BGHU700SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 700 mm Width: 560 mm Height: 40 mm Product specifications: o 1 x 3.80 kW triple crown (wok) burner o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o Front control operation o Automatic ignition... -
Page 10: Electrical Details
Electrical details Rated Voltage: 220 - 240 Vac 50 / 60 Hz Supply Connection: 3A (double pole switched fused outlet with 3mm contact gap) Max Rated Inputs: 0.0008 kW Mains Supply Lead: 3 core x 0.75mm² (Type RR-F <HAR> marked) Gas details Connection: Rp ½... -
Page 11: Gas Hob Surface Layout
Gas hob surface layout BGHU600SS A = 3.00 kW rapid burner B = 1.75 kW semi-rapid burner C = 1.00 kW auxiliary burner D = Control panel BGHU610SS A = 3.80 kW triple crown (wok) burner B = 1.75 kW semi-rapid burner C = 1.00 kW auxiliary burner... -
Page 12: Using The Gas Hob
Using the gas hob Before first use IMPORTANT: You should clean the hob surface (see “Cleaning and maintenance” section). Switching the hob on The following symbols will appear on the control panel, next to each control knob: = gas off Large flame: maximum setting Small flame: minimum setting o The minimum setting is at the end of the anti-clockwise rotation of... -
Page 13: Energy Saving Tips
o To switch the burner off, turn the control knob fully clockwise to the gas off position. o In case of power failure, the burners can be lit by carefully using a match. Energy saving tips BURNERS PANS Minimum Maximum diametre diametre 220 mm... -
Page 14: Cleaning
Cleaning Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. Cleaning the hob top Any residues that are left on the hob top surface from cleaning agents will damage it. -
Page 15: Maintaining The Cast Iron Pan Stands
o Before placing the burners back on the hob top, make sure that the gas jet is not blocked. o IMPORTANT: Make sure that you reassemble the burners in the original way. Maintaining the cast iron pan stands (BGHU610/BGHU700 only) o IMPORTANT: Make sure that the hob surface and pan stands have cooled before you attempt to touch them. -
Page 16: Positioning
85°C above the ambient temperature of the room it is located in, during periods of use. * 600 mm (BGHU600SS / BGHU610SS) * 700 mm (BGHU700SS) o This appliance can be located in a kitchen, a kitchen diner or a bed sitting room. -
Page 17: Unpacking The Appliance
Unpacking the appliance When unpacking the appliance please check that the following items are contained within the packaging: 1 x Hob Pan stands Burner assemblies Instruction manual Warranty card Fixing screws Clamps Sealing strip LPG conversion jets Self-adhesive label for amending the gas category on the appliance’s rating plate (required if the LPG conversion jets are used). -
Page 18: Installing The Appliance
Installing the appliance BGHU600SS / BGHU610SS BGHU700SS o Cut a hole in the worktop that corresponds with the relevant drawing for your hob (above). - Page 19 All models o IMPORTANT: You must have a gap of at least 25 mm between the underneath of the appliance and any surface that is below it. o Carefully turn the hob upside down and place it on a cushioned mat.
-
Page 20: Gas Connection
o Place the clamp (B) over the holes that match the size of the screws. There are one set of screw holes in each corner of the hob. Slightly tighten a screw (C) through the clamp (B) so that the clamp is attached to the hob, but so that you can still adjust the position of it. -
Page 21: Ventilation Requirements
Ventilation requirements o The room containing the hob should have an air supply in accordance with the current edition of BS 5440: Part 2: o The room must have opening windows or equivalent; some rooms may also require a permanent vent. o If the room has a volume between 5 and 10m³, it will require an air vent of 50cm²... -
Page 22: Gas Safety (Installation And Use) Regulations
Gas Safety (Installation and Use) Regulations IMPORTANT: The appliance MUST be connected to the gas supply by use of a 15 mm x ½” female coupler, seal, copper pipe and an isolation tap fitted in an easily accessible position. o It is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety Installation and Use Regulations. -
Page 23: Gas Adjustment (Conversion To Lpg)
Gas adjustment (Conversion to LPG) All work must be carried out by a GASSAFE registered engineer. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. o Remove pan-stands, burners flame spreaders (A). -
Page 24: Minimum Flow Adjustment For Hob Gas Taps
Minimum flow adjustment for hob gas taps. work must carried GASSAFE registered engineer. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. o Switch the burner on and set the knob at the minimum position. -
Page 25: Gas Tap Maintenance
Gas tap maintenance These maintenance operations MUST ONLY be carried out by a GASSAFE registered engineer. IMPORTANT: Before carrying out any maintenance operations, disconnect the appliance from the gas and electricity supplies. If a gas tap becomes stiff to operate, then you should proceed as follows: o Remove the control knobs, pan supports, burners, hob fixing screws and clamps. -
Page 26: Electrical Connection
Electrical connection This appliance must be installed by a qualified person in accordance with the latest edition of the I.E.E. Regulations compliance with manufacturer’s instructions. Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. -
Page 27: My Appliance Isn't Working Correctly
My appliance isn’t working correctly IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge. - Page 29 United Kingdom 11 Beacontree Plaza Gillette Way Reading RG2 0BS Customer Care Telephone 0844 692 3605 Spare Part Telephone 0844 692 3606...
