This is a simplified representation of the TV front panel, side panel control buttons and side inputs.
TV Side panel controls and connections
Menu display. Press to access the on-screen
Press to access the input source mode. Press
repeatedly to change the source to the one
you want to watch. In the MENU screen, the
INPUT button serves as the ENTER button.
Press to adjust the volume. In the MENU screen,
3 VOL +/-
these buttons serve as left/right buttons.
Press to scan through channels. To scan quickly
through channels, press and hold down either
4 CH +/-
+/- . In the MENU screen, these buttons serve
as up/down buttons.
Press to turn on and off the TV.
Receivers IR signals from the remote control.
6 Remote Sensor
Do not put anything near the sensor, which
may block the remote control signal.
7 Power indicator
Haier LED HDTV
