1. BASIC CONCEPTS

Overview
•

Introduction

• About a Configuration
•

About a Snapshot

• About storing Configurations and Snapshots
1.1 Introduction
Overview
Projector Toolset is a software tool to set up, configure, manage and control Barco projectors.
The concept of this Projector Toolset software is modular. The basic package can be extended with sev-
eral optional device plug-in modules, now and in the future available.
The Projector Toolset software works with configurations that can be loaded. Within a configuration, differ-
ent snapshots can be taken. A snapshot represents a current state of a configuration and can be reloaded
to return to this typical state. These terms will be used through the complete software.
Projector Toolset is a stand-alone application that runs on a Java Virtual Machine and that does not require
extra services to run.
Several configurations can be controlled simultaneously. Even when the configurations are connected via
different ways.
1.2 About a Configuration
What is a Configuration?
A Configuration is a collection of projectors with all their current settings, connected to a computer. A
configuration can contain different settings, called snapshots, for all the projectors in the configuration.
1.3 About a Snapshot
What is a Snapshot?
A Snapshot is collection of settings of a configuration. Such a snapshot represents the current state of a
configuration.
A snapshot can contain all settings or specific settings as input settings, lamp settings, layout settings or
projector settings. When restoring a snapshot, only the stored settings will be restored. The others remain
on their current value.
1.4 About storing Configurations and Snapshots
Overview
All information is stored by default in the install directory of Projector Toolset in the subdirectory Workspace.
R5976924 PROJECTOR TOOLSET 16/04/2009
