4. Apply the thermal grease provided in the spares kit to the top of the processor and install the
heat sink atop the processor.
5. Go to step 7.
6. If using a new heat sink, remove the protective covering from the bottom of the heat sink and
place it in position atop the processor.
7. Secure the heat sink to the system board and system board tray with the four captive screws
and attach the heat sink control cable to the system board.
CAUTION:
an X) to evenly seat the heat sink on the processor. This is especially important as the pins on
the socket are very fragile and any damage to them may require replacing the system board.
NOTE: After installing a new processor onto the system board, always update the system ROM to
ensure that the latest version of the BIOS is being used on the computer. The latest system BIOS can
be found on the Web at: http://h18000.www1.hp.com/support/files.

Power Supply

WARNING!
active AC outlet. To avoid possible personal injury and damage to the equipment the power cord
should be disconnected from the computer and/or the AC outlet before opening the computer.
1. Prepare the computer for disassembly
2. Remove the access panel
3. Rotate the drive cage up and disconnect the power cables from all of the drives.
4. Disconnect the power cables from the system board.
5. Rotate the power supply to its full upright position (1), pull the power supply forward (2) until the
posts on the power supply move forward in the power supply bracket (3), and then lift the power
supply straight up and out of the chassis.
Figure 5-53
74 Chapter 5 Removal and Replacement Procedures
Heat sink retaining screws should be tightened in diagonally opposite pairs (as in
Voltage is always present on the system board when the computer is plugged into an
(Access Panel on page
Removing the power supply
(Preparation for Disassembly on page
32).
32).
