Hp Multiseat T100 Thin Client - HP MultiSeat ms6000 Maintenance And Service Manual

HP MultiSeat t100 Thin Client

Table E-2 Specifications
Dimensions
Width (side to side)
Height (without mounting bracket)
Height (with mounting bracket)
Depth (front to back)
Approximate Weight
Without mounting bracket
With mounting bracket
Temperature Range *
Operating**
(max. rate of change is 10° C per hour or 18° F per hour)
Nonoperating
(max. rate of change is 20° C per hour or 36° F per hour)
*Specifications are at sea level with altitude derating of
1° C/300m (1.8° F/1000ft) to a maximum of 3Km
(10,000ft), with no direct, sustained sunlight. Upper limit
may be limited by the type and number of options
installed.
Relative Humidity (non-condensing)
Operating
(max. wet bulb temperature is 28° C or 84.2° F)
Nonoperating
(max. wet bulb temperature is 38.7° C or 101.6° F)
Maximum Altitude (unpressurized)
Operating
(max. allowed rate of change is 457 m per minute or 1500
ft per minute)
Nonoperating
(max. allowed rate of change is 457 m per minute or 1500
ft per minute)
111.7 mm 4.40 in.
28.2 mm 1.11 in
34.8 mm 1.38 in
65.0 mm 2.56 in.
135.7 g 4.78 oz
162.0 g 5.71 oz
10° to 40° C 50° to 104° F
-30° to 60° C -22° to 140° F
** The operating temperature range when the HP
MultiSeat ms6000 Desktop is attached to a flat panel
using the mounting bracket is 50° to 95° F (10° to 35°
C).
10–90% 10–90%
5–95% 5–95%
10,000 ft
3,048 m
30,000 ft
9,144 m
HP MultiSeat t100 Thin Client 113
