Table 5-3
Connector Name
PWR, P1
P2
PWRCPU, P3
PS STAT
SATA PWR1, P160
SATA PWR2, P161
CHFAN, P9
PB/LED, P5
CHFAN2, P11
FRNT_USB1, P24
FRNT_USB2, P25
FRONT AUD, P23
SPRK, P6
COMB, P52
SATA0, P60
SATA1, P61
SATA2, P62
SATA3, P63
PAR, P126
MEDIA, P150
46
Chapter 5 Removal and Replacement Procedures
Cable connections
Connector Color
White
White
White
White
Black
Black
Maroon
Black
Maroon
Yellow
Green
Blue
White
Black
Dark blue
White
Light blue
Orange
Black
Black
Description
Power supply, 6-pin
Power supply, 6-pin
Power supply, 4-pin
Power supply, 6-pin
Optical drive power connector, 4-pin
Hard drive power connector, 4-pin
Chassis fan
Front power button/LED
2nd chassis fan
Front I/O USB
Front I/O USB
Front audio
Internal speaker
Serial port
1st HDD
1st ODD or 2nd HDD if no HDD
present
2nd HDD if ODD present
eSATA port or extra ODD/HDD
connector
Parallel port
Media reader
