To Remove A Power Supply Module - Acer Altos 11000 System User Manual

3. Connect a power cable to the power supply and secure the power cable
by flipping down the wire clip. Plug it into an electrical socket. You will
see a green light when the power supply is functioning properly.
The power supply supplied with the system
accepts input voltage of 100V~240V, 50~60Hz.
7.2

To remove a power supply module:

1. Detach the power cable from the electrical outlet and also from the
power supply. The power indicator light turns off.
2. Unscrew the screw knobs and carefully pull out the power supply until it
detaches from the housing.
26
Installation Guide
