Weight and physical dimensions

Table 12 lists the weight and physical dimensions of the SAN16B-2.

Memory specifications

The switch memory specifications are listed in Table 13.

System general specifications

Table 14 lists the system specifications for the SAN16B-2 switch.
Table 12. Switch specifications
Dimension
Height
Width
Depth
Weight
Table 13. Memory specifications
Memory type
Main memory (SDRAM)
Compact flash
Table 14. General specifications
Specification
Auto-configuring port types
System architecture
System processor
ANSI Fibre-channel protocol
Modes of operation
Fabric initialization
Ethernet port
Terminal port
ASIC
FC-IP (IP over Fibre Channel)
Aggregate switch I/O bandwidth
Port-to-port latency
Value
1U = 4.29 cm (1.69 in.)
42.85 cm (16.87 in.)
30.734 cm (12.10 in.)
4.0 kg (8.8 lb)
Installed Memory
128 MB
256 MB
Descriptions
F_Port, FL_Port, and E_Port
Nonblocking shared-memory switch
PowerPC440GP, 333 MHz CPU
FC-PH (Fibre Channel Physical and
Signalling Interface standard)
Fibre Channel Class 2, Class 3, Class F
Complies with FC–SW–2 6.6
One 10/100 Mbit/sec Ethernet port; accessed
through RJ45 connector
One UART interface for terminal, accessed
through DB9 connector
Goldeneye ASIC for Fibre Channel Switching
Complies with FC-IP 2.3 of FCA profile
128 Gb/sec if all 16 ports running at 4
Gb/sec, full duplex
Less than 2 microseconds with no contention
(destination port is free)
Appendix A. Product specifications
