Hot-Plug I/O Module - HP StorageWorks 600 - Modular Disk System Maintenance And Service Manual

Remove the fan.
2.
CAUTION:
more than one component or blank removed. When removing an active component
permanently, replace it with a blank.
To replace the fan, install it into the fan bay and push until it locks into place.

Hot-plug I/O module

Before removing the component, be sure to do the following:
•
Verify the status of the I/O module to be replaced by reviewing rear panel LEDs and buttons (on
page 56).
•
Be sure that your configuration can support your actions. If the proper redundancy is not in place,
power down the MDS600 before beginning this procedure.
To remove the component:
Be sure the hard drive drawer is closed all the way.
1.
Disconnect the SAS cables.
2.
For best cooling practices, do not operate the enclosure for extended periods with
Removal and replacement procedures 32
