Enterasys Intrusion Prevention System Reporting Manual page 44

Customizing the Dashboard Interface
Figure 2-17
Table 2-7
that filter on interfaces with a status of Up, Down, and Unavailable.
Table 2-7 Systems and Sensors Tab Status Filters
State
Active
Inactive
Unavailable
Upgrading
Unmanaged
Never Deployed
Deleted
Exporting Tables in CSV Format
The tables displayed in the Systems, Sensors, and Interfaces tabs can be exported in CSV (comma
separated values) format and opened immediately or saved as a file.
1. Click on the CSV button to the far right on the Status Totals bar.
If the CSV button is not visible:
–
–
–
2. When prompted, select Open or Save.
3. If you selected Open, the file will be opened using the selected application (such as Microsoft
Excel). If you selected Save, you will be prompted to specify the location.
2-18 Enterasys IPS Analysis and Reporting Guide
Remove or Apply a Filter in the Tabbed Panel
describes the Systems and Sensors tab status filters. The Interfaces tab has similar filters
Description
Filter on Enterasys IPS systems/sensors with a status of Active, meaning that
they are operating normally (the Configuration Channel and Sensor are both up)
Filter on Enterasys IPS systems/sensors with a status of Inactive, meaning that
the Configuration Channel is up but the Sensor is down
Filter on Enterasys IPS systems/sensors with a status of Unavailable, meaning
that the Configuration Channel is down and no additional information about the
system is available
Filter on Enterasys IPS systems/sensors with a status of Upgrading, meaning that
the system/sensor is in the process of being upgraded
Filter on Enterasys IPS systems/sensors with a status of Unmanaged, meaning
that the system/sensor is not managed by the EMS
Filter on Enterasys IPS systems/sensors with a status of Never Deployed,
meaning that the system/sensor has never been successfully deployed
Filter on Enterasys IPS systems/sensors with a status of Deleted, meaning that
the system/sensor has been manually deleted from the EMS. To remove deleted
items, see
Right click in the table and select Export as .csv, or
Resize the Tabbed Panel to display the entire Status Totals bar, or
Click the double right arrows icon on the Status Totals bar which will display a drop
down menu with Export as .csv as an option.
"Removing a Table Entry" on page 2-17.
System Dashboard
