Customizing the Dashboard Interface

Under optimal conditions, these lines are identical, indicating that events are processed as soon as
they are received. Under high load conditions, the event processing rate can lag the event
reception rate, resulting in delays in event reporting. Normally this backlog is cleared once the
incoming event rate settles down.
The Event Cache Traffic graph provides an easy way to quickly see the event load the EMS is
operating under and gauge how well it is keeping up with that load.
Customizing the Dashboard Interface

Customizing the Views Panel

You can resize interface elements in the Dashboard, such as panels. For example, to resize a panel,
mouse over the area between panels until the cursor changes as shown in
and release the panel separator to resize the panels.
Figure 2-5
You can show and/or hide certain interface elements in the Dashboard, such as the entire Views
panel or individual views themselves.
To hide the entire Views panel, click the double left arrows icon as shown in
Figure 2-6
To show the Views panel, click the double right arrows icon as shown in
2-12 Enterasys IPS Analysis and Reporting Guide
Resizing the Views Panel
Hide Views Panel
System Dashboard
Figure 2-5. Click, drag,
Figure 2-6.
Figure 2-7.
