Legacy Reporting
This example shows IPS generated events. IPS events are clearly noted in the event summary.

SummaryByDirection

The SummaryByDirection event summary displays counts of events for each event group for each
direction, as shown in
events inbound, outbound, internal, and external. Clicking on the particular group name takes
you to a SumEvents interface filtered for only events of that group and in that direction.
Figure 11-16

SummaryLast7Days

The SummaryLast7Days event summary displays an event summary of all events over the last
seven days in a clickable spreadsheet as shown in
Figure 11-17

SummaryByGroup

The SummaryByGroup event summary performs the same functions as the EventSummary event
summary, except that it sorts the output by event groups. In some cases, this output can be easier
to analyze than the raw event summary output because the list of events is broken into smaller
groups.
Figure 11-16. Separate bar chart graphs are produced which account for all
Realtime SummaryByDirection
Realtime SummaryLast7Days
Figure 11-17.
Enterasys IPS Analysis and Reporting Guide 11-13
Using the Realtime Console
