Back Panel Components

Intel® Entry Server Chassis SC5299-E UP/DP/WS/BRP User Guide
A
E
G
A. Power Supply
NOTE: Fixed Power Supply shown. Your Power Supply may
vary depending on chassis configuration purchased
B. A/C Power In
NOTE: Fixed Power Supply shown. Your Power Supply may
vary depending on chassis configuration purchased.
C. Alternate external SCSI knockout
D. System Fan
E. I/O Shield
NOTE: I/O connectors vary, depending on the server board
installed. See your server board documentation for
port identification
F. Alternate Serial B port knockout
G. PCI Add-in Card slots
H. PCI Tool-less Card Retention Mechanisms
I. External SCSI knockout
J. Serial B port knockout

Figure 6. Back Panel Components

Server Chassis Features
B
C
D
F
H
I
J
TP00880
7
