Chapter 3

High Density Configuration

High Density Configuration Example

A high density configuration is illustrated in Figure 3-8. For this example, one 41-

EIA Unit Rack (a 2-meter HP Systems or HP System/E rack) is completely filled

with power supplies, servers, and storage units. Two mass storage units

"sandwich" each NetServer.

Figure 3-8. High Density Configuration, Block Diagram

Procedure for Connecting and Routing Cables to the LXr 8500

Branch Circuit A

Branch Circuit B
