Chapter 3
HP NetServer
Lxr 8500
Figure 3-1. Overview of Data Cabling of the HP NetServer LXr 8500 to an HP
NOTE
Figure 3-1 shows an HP Console Switch, which is not
necessary for configuring the system, but is shown for
informational purposes.
The configuration in Figure 3-1 requires 2 UPS (power
supplies) and 2 PDU (power strip) units at both 208 V and at
230/240 V.
Figure 3-2 shows an HP NetServer LXr 8500 connected in Dual Active Mode to a
Rack Storage/12FC.
Procedure for Connecting and Routing Cables to the LXr 8500
Single Bus
Configured
Storage
Dashed Lines Indicate Dual Bus
Configured Storage
Rack Storage/12
Rack Storage/12
29
