Parts List

NOTE
*
This part is not on an exploded view.
Fig
1 Chassis Cover
2
Chassis
3
Front Bezel (with End Caps)
4 Light Pipes
5
Environmental Services Monitoring (ESM) Module
6 Hot Swap Power Supply
7 Hot Swap Fan Unit
8
Power Supply Levers
9 Midplane
* End Cap
*
Disk module tray kit
* Hot Swap Assembly - Tray Bezel
*
Hot Swap Assembly - Filler Panel
*
Hot Swap Cage Key
* SCSI Bridge Cable
*
SCSI Terminator

Configuration

Locking and
Release Mechanism

Single Bus Cabling

The HP Rack Storage/8 provides up to eight hard disk drives on a single SCSI bus.
1. Move the option switches number four and number two to the up positions.
2. Use the short bridge cable included as part of the shipped items and connect the Bus 1 Output
connector and the Bus 2 Input.
78
The part numbers in the list were the ones that were available at the time of
publication. Part numbers may change after publication. HP's parts price list
database will generally contain a reference to the revised part number.
