System Switches

Switch
position
1 - 5 (See table
below)
6 Open
7 Open
8 Closed
9 Open
10 Open

Processor Switch Settings

CPU Speed Switch 1
233 MHz Open
266 MHz Open
300 MHz Open
333 MHz Open

Specifications

Physical Dimensions
Server*
Height: 445 mm (17.5 in)
Width: 191 mm (7.5 in)
Depth: 451 mm (17.75 in)
Weight: 14 Kg (30.8 lbs) Model 1*
Environmental Specifications
Operating altitude:
Non-operating altitude:
Operating temperature:
Non-operating temperature (storage):
Operating humidity:
Non-operating humidity:
Factory
preset
Select processor speed settings. The switch positions may need to
be changed when upgrading the processor (see table below).
Resets the CMOS configuration to the default values. Set the switch
to the closed position and restart the NetServer to reset the CMOS.
Return the switch to the open position and restart the NetServer to
return to normal operation.
Clears the password. Set the switch to the closed position and restart
the NetServer to clear the password. Return the switch to the open
position and restart the NetServer to return to normal operation.
Enable or disable space bar power-on. If you want to enable this
feature, set this switch to Closed. If you want to disable it, set this
switch to Open. This feature must also be configured in the BIOS
using the SETUP utility.
Clear system product code
Reserved
Switch 2 Switch 3
Open
Open
Open
Open
Definition:
Switch 4
Open Closed
Closed Open
Closed Open
Closed Closed
Height: 35 mm (1.4 in)
Width: 467 mm (18.4 in)
Depth: 198 mm (7.8 in)
Weight: 1.9 mm (4.2 lbs)
Keyboard mini-DIN cable: 3 meters (9.9 feet)
3046 m (10,000 ft)
12,200 m (40,000 ft)
5 degrees to 35 degrees C (41 degrees to 95 degrees F)
-40 degrees to 70 degrees C (-40 degrees to 158 degrees
F)
20 % to 80% relative humidity
5% to 95% relative humidity
Switch 5
Closed
Open
Closed
Open
Keyboard
