HP NetServer E45/E50
System Views
Front
View
Technical Reference Card and
Diagnostic Assistant Diskette
(located in pouch)
Power Switch
Power and Disk Drive
Activity LED
Front Panel Key Lock
Locked Position
Unlocked Position
Shelf 4 (mass storage tray provided)
Factory Seal (located on bottom of chassis)
Network
Connector
(Type A Chassis)
Serial B
Serial A
Parallel
Mouse
Keyboard
Monitor
Rear Cooling Fan
Line Voltage Switch
Power Connector
Rear
View
Optional Tape
Backup Drive
(Type B Chassis)
51
