System Views

Customer Serviceable Components
Front Panel
End Caps
SCSI Drives
Drive Activity (LED) Light
In Place/Fault (LED) Light
End Caps
Hot-Swap Hard Drive
Module Keylock
Enclosure
Fan Unit
Power Unit
LEDs
Keylock
Hot swap SCSI-2 hard disk drive modules can be installed in the HP Rack
Storage/8.
This LED glows green to indicate SCSI activity to and from the associated
drive.
The LED lights above each drive indicate that drives status.
The End Caps in the bezel permits access to the enclosure screws that
secure the HP Rack Storage/8 to the rack.
A key is required to remove any of the hot-swap hard drives when the HP
Rack Storage/8 is locked.
Environmental Service
Monitoring Module
Power Unit
Fan Unit
End Caps
75
