Maximum Heat Dissipation Specifications
Physical Specifications
Dimensions
Both the J5xxx and J7xxx workstations use a common chassis, which is
17.5 inches (44.5 cm) high ¥ 13.6 inches (34.5 cm) wide ¥ 21.0 inches
(53.3 cm) deep. Both are also rack-mountable, using the J1458A Rack
Mount Kit.
Net Weights
Minimum Configuration:
Maximum Configuration:
Chapter 5
Specifications and Regulatory Requirements
J5xxx
4163.61 BTU/hr
1050.06 KCAL/hr
J5xxx
74 pounds (34 Kg)
88 pounds (40 Kg)
Specifications
J7xxx
6577.89 BTU/hr
1658.94 KCAL/hr
J7xxx
81 pounds (37 Kg)
96 pounds (44 Kg)
43
