Shipping a rack with an integrated server

NOTE: If the rear slide brackets must adjust to shallower
or deeper third-party columns, see "(Optional) Adjusting
the mid-weight outer slide assemblies (on page 3)."
NOTE: All M4 screws must be torqued to 2.4 Nm (22 lb).
1. Install the mid-weight inner slides, and secure them to the
server, using the required number of M4 x 8-mm screws.
a. Using two M4 x 8-mm screws, secure the mid-weight inner
slides to an HP 2U server.
b. Using two M4 x 8-mm screws, secure the mid-weight inner
slides to an HP 3U server.
c. Using two M4 x 8-mm screws, secure the mid-weight inner
slides to an HP 4U server.
d. Using four M4 x 8-mm screws, secure the mid-weight inner
slides to an HP 5U server.
Using the height of the mid-weight inner slides, mark both sides
2.
of the mid-weight slide-mounting alignment tool.
