Table 8-10
Class: SMX_FanLocation
Property name
Caption
Description
ElementName
Name
PhysicalPosition
ElementLocationTag
ElementLocationTagDesc
SMX_FanElementLocation
8-3-10
SMX_FanElementLocation is used to represent an association between CIM_Location and
CIM_ManagedElement.
Table 8-11
Class: SMX_FanElementLocation
Property name
Element
PhysicalLocation
SMX_FanModule
8-3-11
SMX_FanModule is used to model physical fans on Servers. Please note: Fan numbers for existing
instances do not change when other fans are added and removed.
Table 8-12
Class: SMX_FanModule
Property name
Property implementation
CIM_ManagedElement
Fan n, where n represents the fan position of the fan
instance
The location of the fan n. Refer to fan position n printed
on the system where n represents the fan postion
printed on the system labeling.
User displayable name of this fan location, including
the location . Fan n, where n represents the fan
position printed on the system labeling.
CIM_Location
Unique identifier for this fan location instance
Physical position of this fan. For example on ProLiant
number of the fan position printed on the system
HP_Location
Location string based on
ElementLocationTagDescription. For exampe, on
ProLiant Fan n, where n represents the fan position
printed on the system.
On ProLiant: 0 (HoodTag)
Property implementation
References CIM_ManagedElement
References CIM_Location
Property implementation
CIM_ManagedElement
System Fan 201
