Toner level sensor removal

See "Toner level sensor" on page 7-11
Note the locations of the toner sensors.
1.
Remove the HVPS. See
2.
For yellow and cyan only: Remove the transfer contact assembly. See
removal" on page
Note: Do not remove the springs from the contact assembly as stated in the last step of the procedure.
for the part number.
Yellow
Cyan
Magenta
"High voltage power supply (HVPS) removal" on page
4-92.
Black
4-62.
"Transfer contact assembly
Repair information
5022-xxx
4-83
