Transfer belt removal

See "Transfer belt assembly, C52x" on page 7-15
part number.
1.
Remove all photoconductor units. See
Warning: To avoid damaging the photoconductor drum, hold the photoconductor units by their handle and
place the photoconductor units on a clean surface. Never expose the photoconductor units to light for a
prolonged period of time. See
information.
2.
Disconnect the transfer belt cable (A).
3.
Press the two tabs (B) on either side of the transfer belt assembly, and lift out the transfer belt assembly.
Model C52x
Installation notes: When you installed the new transfer belt and moved all the photoconductor units from the
used one to the new one, the alignment of the toner cartridges and photoconductor units may have changed. For
better color quality, perform the Color Alignment procedure in the Configuration Menu. See
on page 3-24.
1.
Enter the Configuration Menu. (Turn off the printer, press and hold
release the buttons when the clock graphic displays.)
2.
Select Color Alignment. See
"Handing the photoconductor unit" on page 4-2
A B
"Color Alignment" on page
or "Transfer belt assembly, C53x" on page 7-15
"Photoconductor unit removal" on page
A
3-24.
4-70.
for additional
Model C53x
B
"Color Alignment"
and , turn on the printer, and
Repair information
5022-xxx
for the
4-91
