Install the New Passive QIP

4. Attach the CAN cable (Figure 12).

Figure 12 The Voltage sense and CAN cables.

5. Use the settings you recorded on page 8 to set the passive QIP dip switches.

6. Replace the drive sleds.

7. Close and lock the door.

Passive QIP Replacement Guide: Spectra 12000, Spectra 64000 13
