Table 4-1 LANVIEW LEDs (Continued)
LED
Color
RX
Off
(Receive)
Green
Amber
Red
TX
Off
(Transmit)
Green
Red
State
No link.
No activity or port in
standby. Port enabled or
disabled.
Solid. Link, port enabled,
no activity.
Blinking. Link.
Flashing. Link, port
enabled, activity.
Solid. Diagnostic failure.
No activity.
Flashing. Indicates
activity. Rate indicates
data rate. Port enabled.
Flashing. Indicates
collision rate.
Solid. Diagnostic failure.
Recommended Action
None.
None.
None.
None.
Contact Enterasys Networks for assistance.
Ensure that the Spanning Tree Algorithm
(STA) is enabled and that there is a valid
link.
None.
None.
Contact Enterasys Networks for technical
support.
Using LANVIEW
Troubleshooting
4-3
