Troubleshooting

This chapter provides information concerning the following:

• Using LANVIEW

(Section 4.1)
• Troubleshooting Checklist (Section 4.2)
• Using the RESET Button (Section 4.3)
4.1 USING LANVIEW
The 5G102-06 and 5G106-06 use a built-in visual diagnostic and status monitoring system called
LANVIEW. The LANVIEW LEDs shown in Figure 4-1 allow quick observation of the network
status to aid in diagnosing network problems.
Figure 4-1 LANVIEW LEDs
Troubleshooting 4-1
