How to operate the optional 5.1ch decoder & AV selector unit

Setting display

Screen settings of the optional 5.1 ch decoder & AV

selector unit

Up to two external monitors can be connected when the 5.1 ch decoder & AV selector unit is
connected. Separate images can be displayed on each external monitor.

External monitor image settings

Select the image to be displayed on the external monitors.
Press and hold
hear a beep.
Touch
AV Setting
Touch
Monitor 1
and select an image.
● Each time the switch is touched, the
image is changed in the following order
shown below.
DVD VTR1
● The selected image will appear on the
left side of the screen.
BACK
● Touch
The picture setting mode adjustments
will be saved and system will return to
the previous operation screen.
If a VTR or DVD player is not connected to the 5.1 ch decoder & AV selector unit,
no image will be displayed.
until you
FUNC
.
or
Monitor 2
VTR2
after making settings.
